HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
Indication Class
SMX_powerSupplyIndication
Indication ProviderName
“HP Power”
Indication EventID
“2”
Notes
This trap will be generated for this condition.
Trap OID
1.3.6.1.4.1.232.6034
Trap OID Name
cpqHe3FltTolPowerSupplyRemoved
Indication Class
SMX_PowerSupplyIndication
Indication ProviderName
“HP Power”
Indication EventID
“1”
Notes
This trap will be generated for this condition
Trap OID
1.3.6.1.4.1.232.6035
Trap OID Name
cpqHe3FltTolFanDegraded
Indication Class
SMX_FanIndication
Indication ProviderName
“HP Cooling”
Indication EventID
“20”
Notes
This trap will be generated for this condition
Trap OID
1.3.6.1.4.1.232.6036
Trap OID Name
cpqHe3FltTolFanFailed
Indication Class
SMX_FanIndication
Indication ProviderName
“HP Cooling”
Indication EventID
“3”
Notes
Trap OID
1.3.6.1.4.1.232.6037
Trap OID Name
cpqHe3FltTolFanRedundancyLost
Indication Class
SMX_FanIndication
Indication ProviderName
“HP Cooling”
Indication EventID
“5” or “6”
Notes
This trap will be generated for this condition The two
different indications differentiate between redundancy
reduced and redundancy lost.
