2 Overview of the Insight Management MIB
The Insight Management MIB is a modular definition that follows IETF
RFC 1212 for manageable objects and RFC 1215 for traps. Each piece
of information is an object and related objects represent a group. The
information in the MIB represents important device hardware and device
software information. For example, the MIB includes server and
component device information about the operation, performance, security
and configuration of the devices.
The Insight MIB is modular. The following table provides information
about the different files that compose the Insight Management MIB.
MIB File
Description
CPQSTDEQ.MIB
Standard PC Server Equipment information
CPQSINFO.MIB
ProLiant Specific PC Server information
CPQHOST.MIB
Host Server Operating System information
CPQHLTH.MIB
Server Health information
CPQTHRSH.MIB
Settable Threshold information
CPQSM2.MIB
Remote Insight and iLO information
CPQSTAT.MIB
External Status information
CPQIDA.MIB
Intelligent Drive Array information
CPQIDE.MIB
IDE information
CPQSCSI.MIB
SCSI Device information
CPQSTSYS.MIB
Storage Systems information
CPQFCA.MIB
Fibre Array information
CPQNIC.MIB
Network Interface Card information
The Insight MIBs represent an extension to the standard MIB
information already defined in several standard MIB documents (for
example, RFC 1213 or RFC 1271). These extensions offer
additional information that will be available to any SNMP management
application supporting the Insight MIBs.
The Insight MIBs are defined to be modular. A series of MIBs address
various aspects of the computer system. A standard equipment MIB provides
information about the standard equipment of any Industry Standard PC. A
ProLiant system specific MIB provides information about ProLiant specific
extensions to the standard PC information. Other MIBs provide information
about specific sub-systems developed by HP; for example Drive Array or Server
Health sub-systems.
