HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
3 High Level Mapping
The following table provides a general mapping of the MIB files to corresponding
WBEM classes. For greater detail, see the following section, which gives a MIB
variable to WBEM property view of the data.
MIB File
Corresponding WBEM Class
CPQSTDEQ.MIB
SMX_ProcessorChip
SMX_Processor
SMX_ProcessorCapabilities
SMX_HardwareThread
SMX_CacheMemory
SMX_ProcessorLocation
SMX_ProcessorCore
SMX_SystemFirmware
SMX_MPFirmware
SMX_PCISlot
SMX_PCIDevice
SMX_PCISlotElementLocation
CPQSINFO.MIB
SMX_ComputerSystemChassis
SMX_ComputerSystem
SMX_MemoryModule
SMX_MemoryModuleSlot
SMX_MemoryModuleSlotLocation
SMX_MemoryBoard
SMX_PCISlot
SMX_BladeEnclosureCS
SMX_BladeEnclosureFW
SMX_BladeEnclosureLocation
SMX_ManagementProcessor
CPQHOST.MIB
SMX_OperatingSystem
SMX_ComputerSystem
SMX_SMXSoftwareIdentity
SMX_EthernetSoftwareIdentity
SMX_EthernetPortControllerSoftwareIdentity
SMX_FCHBASoftwareIdentityDrv
SMX_ComputerSystemPackage
SMX_SystemFirmware
SMX_BladeEnclosureFW
SMX_EthernetPortControllerFirmwareIdentity
SMX_FCHBAFirmwareIdentityBIOS
SMX_FCHBAFirmwareIdentityFW
