The requested information is returned in the log file, which, in this example, is named log.txt.
The contents of the log file are shown below:
<GET_GLOBAL_SETTINGS>
<SESSION_TIMEOUT VALUE="30"/>
<ILO_FUNCT_ENABLED VALUE="Y"/>
<F8_PROMPT_ENABLED VALUE="Y"/>
<REMOTE_CONSOLE_PORT_STATUS VALUE="3"/>
<REMOTE_CONSOLE_ENCRYPTION VALUE="N"/>
<PREFER_TERMINAL_SERVICES VALUE="N"/>
<HTTPS_PORT VALUE="443"/>
<HTTP_PORT VALUE="80"/>
<REMOTE_CONSOLE_PORT VALUE="23"/>
<TERMINAL_SERVICES_PORT VALUE="3389"/>
<VIRTUAL_MEDIA_PORT VALUE="17988"/>
<MIN_PASSWORD VALUE="4"/>
</GET_GLOBAL_SETTINGS>
Setting a configuration
A specific configuration can be sent to the iLO 2, iLO 3 or iLO 4 by using the command format:
/opt/hp/tools # ./hponcfg -f add_user.xml -l log.txt
In this example, the input file has contents:
<!–Add user with minimal privileges to test default setting of assigned privileges to 'N'—>
<RIBCL version="1.2"/>
<LOGIN USER_LOGIN="x" PASSWORD="x">
<USER_INFO MODE="write">
<ADD_USER USER_NAME="Landy9" USER_LOGIN="mandy9"
PASSWORD="floppyshoes">
<RESET_SERVER_PRIV value="Y" />
<ADMIN_PRIV value="Y" />
</ADD_USER>
</USER_INFO>
</LOGIN>
</RIBCL>
The specified user will be added to the device.
HPONCFG command-line examples
This section provides sample examples to run the utility.
Table 3 hponcfg command-line examples
DescriptionCommand-line argument
This argument displays help information.hponcfg -h
This argument returns the host server name and serial number.hponcfg -g
To view the command usage options, run the following command:
/opt/hp/tools # ./hponcfg —h
All options supported by the command are listed in the output.
To get the host server name and serial number, run the following command:
/opt/hp/tools # ./hponcfg —g
The following output is displayed:
Firmware Revision = 2.05 Device type = iLO 2 Driver name = hpilo
Host Information:
Server Name: localhost.americas.hpqcorp.net
Server Number: 000000000
To set the minimum firmware level, run the following command:
