Size: 146 GB
Rotational Speed: 10000
Firmware Revision: HPDE
Serial Number: 6SD3EVBH0000B144Q7RD
Model: HP EG0146FAWHU
Current Temperature (C): 37
Maximum Temperature (C): 49
PHY Count: 2
PHY Transfer Rate: 6.0GBPS, Unknown
unassigned
physicaldrive 1I:1:3
Port: 1I
Box: 1
Bay: 3
Status: OK
Drive Type: Unassigned Drive
Interface Type: SAS
Size: 146 GB
Rotational Speed: 10000
Firmware Revision: HPDE
Serial Number: 6SD3FK4A0000B145J6JK
Model: HP EG0146FAWHU
Current Temperature (C): 37
Maximum Temperature (C): 48
PHY Count: 2
PHY Transfer Rate: 6.0GBPS, Unknown
...
These examples are not inclusive of all the capabilities of the HPACUCLI command. Commands
and options for additional operations using the HPACUCLI, such as creating a logical drive, are
documented in the HP Array Configuration Utility User Guide.
Generating an ADU report (diagnostics) from within HPACUCLI for ESXi
5.0 and updates
The ACUCLI application contains the ability to generate a diagnostic report of the system and its
Smart Array storage configuration. The following steps are required in order to obtain an ADU
report from a remote machine running ESXi 5.0 and updates.
1. Obtain and install the HP Array Diagnostics and SmartSSD Wear Gauge Utility:
1. Browse to http://www.hp.com
2. Click on Support & Drivers
3. Select Drivers & Software
4. In the search box, type HP Array Configuration Utility
5. Select the operating system of the client machine that will be used to remotely access the
machine running ESXi 5.0 and updates.
6. Under the Software – System Management menu, proceed to download the HP ProLiant
Array Diagnostics and SmartSSD Wear Gauge Utility by clicking on the link.
NOTE: The desired version is 9.x or newer.
7. Install the Windows component or Linux RPM package onto the client machine.
2. The location where the package has installed the included applications and then update your
system path to include this location.
3. The client machine used to access the remote ESXi 5.0 and updates machine must also have
the vSphere CLI esxcli command line tool installed and must be accessible through the
system path. Ensure that the client machine location is included in the path.
