Safety warning …………………………………………………………………………………………………………………………………2

Product features .………………………………………………………………………………………………………………………………2

1.Technical parameters …………………………………………….…………………………………………………………………………2

2.Models and specifications ..…………………………………………………………………………………………………………………2

3.Diagram and installing size …………………………………………………………………………………………………………………2

4.Wiring diagram ………………………………………………………………………………………………………………………………2

4.1 Connecting sensors …….….……………………………………………………………………………………………………………3

4.1.1 Thermocouple ………………………...………………………………………………………………………………………………3

4.1.2 Dual lines PT100 sensor……….……..………………………………………………………………………………………………3

4.1.3 RTD sensor……….……………………………...……………………………………………………………………………………3

4.2 Power supply connection ……………..…………………………………………………………………………………………………3

4.3 connection for control signal output ……………………………………………………………………………………………………3

4.4 Connection for alarm control ……………………………………………………………………………………………………………3

5.Panel instruction ……………..………………………………………………………………………………………………………………3

6.Operation instruction ...………………………………………………………………………………………………………………………3

6.1Display status ……………..………………………………………………………………………………………………………………3

6.2 View output value ………………………………...………………………………………………………………………………………3

6.3 Automatic/Manual control switch ………………………………………………………………………………………………………3

6.4 Value setting ……………...………………………………………………………………………………………………………………3

6.5 Launch self-tuning function ……...………………………………………………………………………………………………………3

6.6 Workflow for setting …………………………………………………………………………………………………………………...…4

6.7 Parameters setting ………………………………………………………………………………………………………………………4

6.8 Parameters related to alarm output: “HiAL,LoAL,dHAL,dHAL,dF,ALP,CF” ……..……………….……………..……………………5

6.8.1 Alarm parameters: HiAL,LoAL,dHAL,dHAL …………………………….……………………………………………………….…5

6.8.2 Defining parameter for alarm ALP ………………………………………………………………………..………………………5

6.8.3 Hysteresis Band dF …………………………………………………………………………………………………………………5

6.8.4 Function parameter CF ……………………………………………………………………………………………………………..5

6.9 Parameters related to input “Sn,diP,diL,diH,DL,Sc” …………………………………………………………………….……………5

6.9.1 Sensor type input “Sn” …………………………………………………………………………………………………………...…5

6.9.2 Decimal point position“diP” …………………………………………………………………………………………………………5

6.9.3 Definition parameters "diH" and "diL" for linear input range …………………………..…………………………………………5

6.9.4 Filtering parameter“dL”………………………………………………………………………………………………………………5

6.9.5 Sensor Calibration“Sc”………………………………………………………………………………………………………………5

6.10 Parameters related to control output“oPI,oPL,oPH,CtrL” …………………………………………………………………...………5

6.10.1 Output mode parameters "oPI", "oPL" and "oPH" are used for limiting output …………………………………………..……5

6.10.2 Adjustment mode parameter "CtrL" ………………………………………………………………………………………………6

6.11 PID control parameters related to self-tuning “M50, P, t” and functional parameter “CtL”……………………………………..6

6.11.1 6.11.1 Holding parameter "M50" …………………………………………………………………………………………………..6

6.11.2 Rate parameter "P" ……………………………………………………………………………………….………………………6

6.11.3 Hysteresis time "t"…………………………………………………………………………………………………………..………6

6.11.4 Function parameter "CtL" ………………………………………………………………………………………………………….6

6.12 Communication parameter “Addr、bAud” ……………………………………………………………………………………………6

6.13 Field parameter "EP1 - EP8" ……………………..……………………………………………………………………………………7

6.14 Permission for parameters “Loc”“LOC” ……………………………………………………………………………………………7

6.15 Common faults and handling methods ……………………………………………………………………………….………………7

7 Wiring instruction ……………………………………………………………………………………………………………………………7

7.1 Directly control load by the internal relay of the instrument ..…………………………………………………………………………7

7.2 Control the load via external contactor …………………………………………………………………………………………...……7

7.3 SSR control ……………………………….……………………………………………………………………………………………7

7.4 Solenoid valve or relay control ………..………………………………………………………………………………………………8

7.5 Control load via external contactor (24V) …………………………………………………………………………………………..…8

8.Field application example …………………………………………………………………………………………………………………..8

User Manual

ITC-100 PID Temperature Controller

V1.0 2015-6-30

Contents

www.ink-bird.com, CS@ink-bird.com

Summary of content (9 pages)

PAGE 1
ITC-100 PID Temperature Controller User Manual V1.0 2015-6-30 Contents Safety warning …………………………………………………………………………………………………………………………………2 Product features .………………………………………………………………………………………………………………………………2 1.Technical parameters …………………………………………….…………………………………………………………………………2 2.Models and specifications ..…………………………………………………………………………………………………………………2 3.Diagram and installing size …………………………………………………………………………………………………………………2 4.Wiring diagram ………………………………………………………………………………………………………………………………2 4.
PAGE 2
■Safety warning 2.Models and specifications ●It’s a must to use this product within its specification and using scope.
PAGE 3
4.1 Connecting sensors 6. Operation instruction Please refer to the input sensor reference table to select sensor type and set the code. The default setting of sensor type is type K thermocouple. If other type 6.1 Display status sensor was adopted, it’s a must to reset the configuration. After power on, the instrument will conduct self-tuning, then enter measuring If error occurred when some thermocouples are used in different environments, and monitoring status automatically.
PAGE 4
6.7 Parameters setting 6.6 Workflow for setting After instrument powered on and run self-inspection, press “SET” key for Table 2: parameters setting and definition Parameter over 2 seconds to enter parameters setting mode. User can press “︽” Definition Value range Unit Default Remarks HIAL Upper alarm limit -1999~+9999 1℃ 9999 See 6.8.1 LoAL Lower alarm limit -1999~+9999 1℃ -9999 See 6.8.1 confirm and go for setting for another function.
PAGE 5
6.9 Parameters related to input “ Sn, diP, diL, diH, DL, Sc” 6.8 Parameters related to alarm output: “HiAL, LoAL, dHAL, dLAL、 dF, ALP, CF” 6.9.1 Sensor type input “Sn” Table 4: sensor input code and measuring range 6.8.1 Alarm parameters: "HiAL、LoAL、dHAL、dLAL".
PAGE 6
current output). Output current are 0-10mA and 2-40mA. stable stage is 700℃, while when the output is 0%, the temperature of When oPI=2, output mode is time proportioning output, and AL1 act as electric furnace is room temperature 25℃, then M50 (optimal value) is output synchronizing with main output. Under this mode, the AL1 of the 700-25=675℃. instrument can’t be used to output alarm signals as it’s used as output. M50 is mainly for adjusting the integral action of adjusting algorithm.
PAGE 7
6.13 Field parameter "EP1 - EP8" 7. Wiring instruction After setting the instrument, most parameters don’t need to be amended 7.1 Directly control load by the internal relay of the instrument. at field. Besides, operators generally don’t understand many parameters, and there is risk of fault caused by wrong setting by operators. Generally, intelligent instrument has parameter lock (Loc) function. Common parameter lock will lock all the parameters.
PAGE 8
7.4 Solenoid valve or relay control 8. Field application example For example, the application of instrument for oven. Following example is based on ITC-100RH and ITC-100VH, the required temperature is 150 ºC, and the high limit is 160ºC. Figure 11:ITC-100RL Wiring diagram ITC-100RL is generally used for low voltage devices. It’s a must to pay Figure 13:ITC-100RH Wiring diagram attention to whether the power supply voltage and alarm voltage is within the stipulated range when wiring. 7.
PAGE 9
Power On Initial display ︽ Setting target temperature SV=150 SET Setting Alarm value for high limit Setting HIRL=160, more setting of alarms, please check 6.8.1 SET *if don't need to set this parameter, press SET key to run into next setting. Setting Control mode Keep the Default value SET Setting Input sensor value Sn=20 (CU=20, more detail please check 6.9.
