Motherboard Logo Program (MLP) Intel® Desktop Board DP55SB MLP Report 8/31/2009 Purpose: This report describes the DP55SB Motherboard Logo Program testing run conducted by Intel Corporation.
THIS TEST REPORT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE. Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by the sale of Intel products.
Copyright © 2009, Intel Corporation. All rights reserved.
Contents Introduction ............................................................................................................ 5 Terms and Definitions............................................................................................................... 5 Desktop Board Configuration .................................................................................. 6 Desktop Board DP55SB Final Configuration Report: Completion of MLP ..................................... 6 Board Information .....
Introduction Terms and Definitions Term Definitions WHQL Windows* Hardware Qualification Lab WLK Windows Logo Kits MLP Motherboard Logo Program. For further information see: http://www.microsoft.com/whdc/hwtest/default.mspx AP Machine Audio Precision Machine Winqual Windows Qualification MSFT Tested Product List Tested Products List. You can view the Windows Marketplace for tested products list at: http://winqual.microsoft.com/HCL/ProductList.
Desktop Board Configuration Desktop Board DP55SB Final Configuration Report: Completion of MLP Data in this section reflects system configuration at time of MLP submission. Board Information Product Code1 BIOS String/Model Technologies NOT Logo’d (yet) DP55SB KGIBX10J.86A.3314.2009.0813.1450 N/A - all technologies logo’d Processor Speed 2.93 GHz Family Intel® Core™ i7 Bus Speed / DMI 2.
Onboard Integrated Devices and Driver for Vista 32-bit and 64-bit Technology OS Version Package version Chipset Update Utility Windows Vista 9.1.1.1013 9.1.1.1015 Intel® Chipset Software Utility Windows Vista 64-bit 9.1.1.1013 9.1.1.1015 Audio Windows Vista 6.0.1.5892 5892 Realtek Windows Vista 64-bit 6.0.1.5892 5892 LAN Intel® PRO Network Connections Windows Vista 10.7.31.0 14.3 Windows Vista 64-bit 10.7.31.0 14.3 Windows Vista 1.8.2009.514 2.1.2009.
Errata and Contingencies Expiry ID Operating System Failing Test Date Number Type Error Description Windows 7 PCI Hardware Compliance Test For Systems 12/31/2009 401 Erratum The following PCI Compliance test failure is acceptable: Bit 15 (Bridge Configuration Retry Enable) in the Device Control register (offset 8h) in the PCI Express Capability table must be read-only and always return 0 as it is reserved for devices other than PCI Express to PCI/PCI-X Bridges.
Expiry ID Operating System Failing Test Date Number Type Error Description Windows 7 1)UAA Test Win7 (System) 12/1/2009 513 Erratum UAA Test requires the Traffic Priority bit to be read/write however there are two specs that apply, and they conflict. One says the bit must be read/write, the other says it must be readonly. Contact has been made with the author of both specs (Intel) but until this point is clarified we cannot fail submissions containing this test failure.
Test Notes Operating System Test Description Windows 7 and Vista BIOS download Internal: http://bios.intel.com/downloads/ Windows 7 and Vista BIOS setup Please make sure the BIOS setting are as below, otherwise use default settings. External: http://www.intel.
