Windows Hardware Certification (WHC) Intel® Desktop Board DH87MC Desktop/Motherboard WHC Report 8/15/2013 Purpose: This report describes the DH87MC Windows Hardware Certification testing run conducted by Intel Corporation.
THIS TEST REPORT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE. Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by the sale of Intel products.
Contents Introduction .............................................................................................................4 Terms and Definitions............................................................................................................. 4 Desktop Board Configuration ...................................................................................5 Desktop Board DH87MC Final Configuration Report: Completion of WHC ................................... 5 Board Information..........
Introduction Terms and Definitions Term Definitions WHQL Windows* Hardware Qualification Lab WHCK Windows Hardware Certification Kit MLP Motherboard Logo Program. For further information see: http://msdn.microsoft.com/en-us/windows/hardware/gg463010.aspx AP Machine Audio Precision Machine Winqual Windows Qualification MSFT Tested Product List Tested Products List. You can view the Windows Marketplace for tested products list at: http://winqual.microsoft.com/HCL/ProductList.
Desktop Board Configuration Desktop Board DH87MC Final Configuration Report: Completion of WHC Data in this section reflects system configuration at time of WHC submission. Board Information Product Code 1 BIOS String/Model Technologies NOT Logo’d (yet) DH87MC MCH8710H.86A.0043.2013.0412.2225 N/A - all technologies logo’d Processor Speed 3.5GHz Family Intel Core i7 4770K Bus Speed 100 MHz Motherboard Board AA # G74242-301 Board FAB # C (eg.
Onboard Integrated Devices and Driver for Windows 7 32-bit Technology Chipset Update Utility Intel® Chipset Software Utility Graphics Intel® HD Graphics 4600 Audio Realtek LAN ® Intel WGI217V MEI ® Intel Management Engine OS Version Package version Windows 7 32-bit V9.4.0.1017 INF_allOS_9.4.0.1017_ PV Windows 7 32-bit V9.18.10.3071 GFX_Win8_Win7_64_9. 18.10.3071_PV Windows 7 32-bit V6.0.1.6870 AUD_Win8_Win7_6.0.1. 6870_PV Windows 7 32-bit V12.6.47.0 LAN_Win8_Win7_12.6. 47.0_(18.
Errata and Contingencies Expiry Date ID Number Type Error Description 3/31/2014 1039 Erratum Input Payload should be 0x1d, but is instead 0x0. This is being requested as a change to the HDAudio spec UAA Test (System) 10/1/2013 244 Contingency Section 3.3.14 of the Intel High Definition Audio specification mandates a reset value of 0 for the Interrupt Control register on HD Audio controllers.
