Intel® RAID RS2, RS25, RMS2, and RMS25 Family Products featuring 6Gb/s SAS and SATA Capability Product List and Configuration Guide A reference guide to assist customers in ordering RAID products. Revision 4.
Revision History November 11 – Rev0.5 – First revision. November 11 – Rev0.7 – Added chip model for each controller and module. Added cable information. December 11 – Rev1.0 – Initial public release. July 12 – Rev2.0 – Added RS25FB044 and cable information. November 12 – Rev3.0 – Updated RAID product pictures and compatible matrix table. March 13 – Rev4.0 – Added RCS25ZB040, RCS25ZB040LX, and AXXRMFBU3. Disclaimer ® INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS.
CONTENTS REVISION HISTORY............................................................................................................................................................. 2 CONTENTS................................................................................................................................................................................. 3 RAID PRODUCT ORDER CODES .................................................................................................................
RAID PRODUCT ORDER CODES 1.1 Product Descriptions – Overview ® Intel 6Gb RAID Products. Including RAID controllers, modules, and expanders. Customer orders an RAID ® solution validated across Intel Server Product line and perhaps a cable (see details below).
1.2 Intel® RAID Controller Order Codes Image Product Code MM UPC Description Minimum Order Quantity ® Intel RAID SSD Cache Controller RCS25ZB040 LSI* SAS2208 ROC 6Gb/s SAS/SATA, x8 PCIe 3.0 4 internal ports MD2 Low Profile, half-length form factor Support RAID 0,1,10,5,6,50,60 Cables are not included RCS25ZB040 924659 00735858254625 5 RCS25ZB040 Compatible Matrix ® Intel RAID SSD Cache Controller RCS25ZB040LX LSI* SAS2208 ROC 6Gb/s SAS/SATA, x8 PCIe 3.
Image Product Code MM UPC Description Minimum Order Quantity ® Intel RAID Controller RS25NB008 LSI* SAS2208 ROC 6Gb/s SAS/SATA, x8 PCIe 3.0 8 external ports 1GB embedded memory MD2 Low Profile, half-length form factor Support RAID 0,1,10,5,6,50,60 RAID Premium Feature Key supported Cables are not included RS25NB008 919567 00735858222594 5 RS25NB008 Compatible Matrix ® Intel RAID Controller RS2VB080 LSI* SAS2108 ROC 6Gb/s SAS/SATA, x8 PCIe 2.
Image Product Code MM UPC Description Minimum Order Quantity ® Intel RAID Controller RT3WB080 LSI* SAS2108 ROC 6Gb/s SATA, x8 PCIe 2.0 8 internal ports 256MB embedded memory MD2 Low Profile, half-length form factor Support RAID 0,1,10,5,6,50,60 RAID Premium Feature Key supported Cables are not included RT3WB080 911121 00735858217859 5 RT3WB080 Compatible Matrix ® Intel RAID Controller RS2SG244 LSI* SAS2108 ROC 6Gb/s SAS/SATA, x8 PCIe 2.
Image Product Code MM UPC Description Minimum Order Quantity ® Intel RAID Controller RS2BL080 “DE” (RS2BL080 supporting Disk Encryption) LSI* SAS2108 ROC 6Gb/s SAS/SATA, x8 PCIe 2.
Image Product Code MM UPC Description Minimum Order Quantity ® Intel RAID Controller RS2PI008 “DE” (RS2PI008 supporting Disk Encryption) LSI* SAS2108 ROC 6Gb/s SAS/SATA, x8 PCIe 2.0 8 external ports 512MB embedded memory MD2 Low Profile, half-length form factor Support RAID 0,1,10,5,6,50,60 RAID Premium Feature Key supported Cables are not included RS2PI008DE 904919 00735858212878 5 RS2PI008DE Compatible Matrix ® Intel RAID Controller RS2WC080 LSI* SAS2008 Processor Chip 6Gb/s SAS/SATA, x8 PCIe 2.
1.3 Intel® Integrated RAID Order Codes Image Product Code MM UPC Description Minimum Order Quantity ® RMS25PB080 924868 00735858238946 Intel Integrated RAID Module RMS25PB080 LSI* SAS2208 ROC 6Gb/s SAS/SATA x8 PCIe 3.
Image Product Code MM UPC Description Minimum Order Quantity ® RMS25CB040 924872 00735858238984 Intel Integrated RAID Module RMS25CB040 LSI* SAS2208 ROC 6Gb/s SAS/SATA x8 PCIe 3.0 4 internal ports 1GB embedded memory Require one 80-pins on-board module connector Support RAID 0,1,10,5,6,50,60 RAID Premium Feature Key supported Cables are not included 5 RMS25CB040 Compatible Matrix ® RMT3CB080 924873 00735858238991 Intel Integrated RAID Module RMT3CB080 LSI* SAS2208 ROC 6Gb/s SAS/SATA x8 PCIe 3.
Image Product Code MM UPC Description Minimum Order Quantity ® RMS25JB080 917087 (being updated to 924452) 00735858239004 Intel Integrated RAID Module RMS25JB080 LSI* SAS2308 Processor Chip 6Gb/s SAS/SATA x8 PCIe 3.
Image Product Code MM UPC Description Minimum Order Quantity ® AXXRMS2LL080 907855 00735858215749 Intel Integrated RAID Module RMS2LL080 LSI* SAS2008 Processor Chip 6Gb/s SAS/SATA, x4 PCIe 2.0 8 internal ports 2MB Context, no BBU option Require one 50-pins on-board module connector Support RAID 0,1,1E Eight SATA cables included 5 RMS2LL080 Compatible Matrix ® AXXRMS2LL040 907856 00735858215763 Intel Integrated RAID Module RMS2LL040 LSI* SAS2008 Processor Chip 6Gb/s SAS/SATA, x4 PCIe 2.
1.
ACCESSORY ORDER CODES 1.
1.6 RAID Premium Feature Key Image 1.
Image NOTE: In the following images, straight connectors and right-angel connectors are not clearly shown. Product Code MM UPC Description Minimum Order Quantity AXXCBL500MSMS 921055 00735858245289 Each set provides two 500mm cables with four port mini-SAS 8087 connectors on both ends. The 8-pin side-band SGPIO physical connection is embedded. 1 AXXCBL600MSMS 921048 00735858245272 Each set provides two 600mm cables with four port mini-SAS 8087 connectors on both ends.
Image NOTE: In the following images, straight connectors and right-angel connectors are not clearly shown. Product Code MM UPC AXXCBL1030MR7R 921079 00735858245258 Description Minimum Order Quantity Each set provides two 1030mm cables with a four port Mini-SAS 8087 connector on one end and four 7-pin SATA style pins on the other end. The 8-pin side-band SGPIO cable with a “Y type” header (one with 4-pin and one with 5-pin) is included.
RAID SKU COMPATIBLE MATRIX 1.8 RAID Product Compatible Matrix Note: For the latest support information, refer to Tested Hardware and Operating System List (THOL) of each RAID product available at http://www.intel.com/support.
Product Code Supported Board RS25AB080 S1400FP Product Family S1400SP Product Family S2400EP Product Family S2400GP Product Family S2400SC Product Family S2600CO Product Family S2600CP Product Family S2600GL Product Family S2600GZ Product Family S2600IP Product Family S2400BB Product Family W2600CR Product Family S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP S1200BTL S1200BTS SC5650SCWS SR1630BC SC5650BCDP SR1690WB SR1695WB SR2612UR SR1630GP SR1630HGP SR1600UR SR2600UR SR2625UR SR1625UR SC565
Product Code Supported Board RS25NB008 S1400FP Product Family S1400SP Product Family S2400EP Product Family S2400GP Product Family S2400SC Product Family S2600CO Product Family S2600CP Product Family S2600GL Product Family S2600GZ Product Family S2600IP Product Family S2400BB Product Family W2600CR Product Family S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP S1200BTL S1200BTS For external storage S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP S1200BTL S1200BTS SR1625URR SR2600URBR
Product Code Supported Board RS25DB080 S1400FP Product Family S1400SP Product Family S2400EP Product Family S2400GP Product Family S2400SC Product Family S2600CO Product Family S2600CP Product Family S2600GL Product Family S2600GZ Product Family S2600IP Product Family S2400BB Product Family W2600CR Product Family S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP S1200BTL S1200BTS S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP S1200BTL S1200BTS SC5650SCWS SR1630BC SC5650BCDP SR1690WB SR1
Product Code RS2WG160 RS2BL040 RS2BL080 RS2BL080DE RS2BL080SNGL Supported Board Supported System S5000PSL S5000XSL S5000XVN S5000VSA S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S3420GP SC5650HCBRP SC5650SCWS S5000PSL S5000XSL S5000XVN S5000VSA S5000PAL S5000XAL S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S7000FC4UR S3420GP S1200BTL S1200BTS SR1690WBR SR1695WB SC5650HCBRP SC5650SCWS SR2612UR S5000PSL S5000XSL S5000XVN S5000VSA S5000PAL S5000XAL S5520UR S5500WB S5500BC S5520HC S5500HCV S55
Product Code RS2MB044 RS2PI008 RS2PI008DE RS2WC080 RS2WC040 Supported Board S5000PSL S5000XSL S5000XVN S5000VSA S5000PAL S5000XAL S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S7000FC4UR S3420GP S3200SH S1200BTL S1200BTS Supported System SR1690WBR SR1695WB SC5650HCBRP SC5650SCWS SR2612UR S5000PSL S5000XSL S5000XVN S5000VSA S5000PAL S5000XAL S5520UR S5500WB S5500BC S5520HC S5500HCV S5520SC S7000FC4UR S3420GP S1200BTL S1200BTS For external storage S5000PSL S5000XSL S5000XVN S5000VSA S5000PAL S500
Product Code RMS25PB080 RMS25PB040 RMT3PB080 (Module) RMS25CB080 RMS25CB040 RMT3CB080 (Module) RMS25KB080 RMS25KB040 (Module) RMS25JB080 RMS25JB040 (Module) RMS2MH080 (Module) Supported RAID Premium Feature Key Supported Backup Unit Supported Board Supported System S1400FP Product Family S1400SP Product Family S2400EP Product Family S2400GP Product Family S2400SC Product Family S2600CO Product Family S2600CP Product Family S2600GL Product Family S2600GZ Product Family S2600IP Product Family S2400B
Product Code RMS2AF080 RMS2AF040 (Module) RMS2LL080 RMS2LL040 (Module) Supported Board S5520UR S5500WB S5520HC/HCT S5520HCV S5520SC S3420GP S1200BTL S5520UR S5500WB S5520HC/HCT S5520HCV S5520SC S3420GP S1200BTL Supported RAID Premium Feature Key Supported Backup Unit SR1690WBR SR1695WB SR1600UR SR1600URHS SR1625UR SR1625URSAS SR2600URBRP SR2600URLX SR2600URSATA SR2625URBRP SR2625URLX SR2625URLXT SR2612UR NA NA SR1690WBR SR1695WB SR1600UR SR1600URHS SR1625UR SR1625URSAS SR2600URBRP SR2600URLX SR26
