Microsoft Exchange Server Jetstress
- Stress Test Result Report
3/5/2009 7:41:26 PM -- Jetstress testing begins ...3/5/2009 7:41:26 PM -- Prepare testing begins ...3/5/2009 7:41:32 PM -- Attaching databases ...3/5/2009 7:41:32 PM -- Prepare testing ends.3/5/2009 7:41:32 PM -- Dispatching transactions begins ...3/5/2009 7:41:32 PM -- Database cache settings: (minimum: 128.0 MB, maximum: 1.0 GB)3/5/2009 7:41:32 PM -- Database flush thresholds: (start: 10.2 MB, stop: 20.5 MB)3/5/2009 7:41:37 PM -- Database read latency thresholds: (average: 0.02 seconds/read, maximum: 0.1 seconds/read).3/5/2009 7:41:37 PM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.1 seconds/write).3/5/2009 7:41:39 PM -- Operation mix: Sessions 12, Inserts 25%, Deletes 10%, Replaces 50%, Reads 15%, Lazy Commits 80%.3/5/2009 7:41:39 PM -- Performance logging begins (interval: 15000 ms).3/5/2009 7:41:39 PM -- Attaining prerequisites: 3/5/2009 7:47:42 PM -- \Database (JetstressWin)\Database Cache Size, Last: 967401500.0 (lower bound: 966367600.0, upper bound: none)3/6/2009 7:47:44 PM -- Performance logging ends.3/6/2009 7:47:44 PM -- JetInterop batch transaction stats: 569497, 569587, 570316, and 570129.3/6/2009 7:48:47 PM -- Dispatching transactions ends.3/6/2009 7:48:47 PM -- Shutting down databases ...3/6/2009 9:24:10 PM -- Instance2840.1 (complete), Instance2840.2 (complete), Instance2840.3 (complete), and Instance2840.4 (complete)3/6/2009 9:24:11 PM -- Performance logging begins (interval: 30000 ms).3/6/2009 9:24:11 PM -- Verifying database checksums ...3/6/2009 10:10:32 PM -- M: (100% processed), N: (100% processed), O: (100% processed), and P: (100% processed)3/6/2009 10:10:33 PM -- Performance logging ends.3/6/2009 10:10:33 PM -- C:\Data\Jetstress\DBChecksum_2009_3_6_21_24_10.blg has 92 samples.3/6/2009 10:10:37 PM -- C:\Data\Jetstress\DBChecksum_2009_3_6_21_24_10.html is saved.3/6/2009 10:10:37 PM -- Verifying log checksums ...3/6/2009 10:10:41 PM -- L:\01 (8 logs passed), L:\02 (22 logs passed), L:\03 (22 logs passed), and L:\04 (21 logs passed)3/6/2009 10:10:41 PM -- C:\Data\Jetstress\Stress_2009_3_5_19_41_37.blg has 5784 samples.3/6/2009 10:10:41 PM -- Creating test report ...3/6/2009 10:11:47 PM -- Volume M: has 0.0158 for Avg. Disk sec/Read.3/6/2009 10:11:47 PM -- Volume N: has 0.0165 for Avg. Disk sec/Read.3/6/2009 10:11:47 PM -- Volume O: has 0.0151 for Avg. Disk sec/Read.3/6/2009 10:11:47 PM -- Volume P: has 0.0173 for Avg. Disk sec/Read.3/6/2009 10:11:47 PM -- Volume L: has 0.0045 for Avg. Disk sec/Write.3/6/2009 10:11:47 PM -- Volume L: has 0.0000 for Avg. Disk sec/Read.3/6/2009 10:11:47 PM -- Test has 4.86722147380135 Maximum Database Page Fault Stalls/sec.3/6/2009 10:11:47 PM -- Test has 0 Database Page Fault Stalls/sec samples higher than 0.3/6/2009 10:11:47 PM -- C:\Data\Jetstress\Stress_2009_3_5_19_41_37.xml has 5759 samples queried.
Microsoft Exchange Server Jetstress
- Test Result Report
Microsoft Exchange Server Jetstress
- Performance Test Result Report
3/5/2009 8:47:51 AM -- Jetstress testing begins ...3/5/2009 8:47:51 AM -- Prepare testing begins ...3/5/2009 8:47:58 AM -- Attaching databases ...3/5/2009 8:47:58 AM -- Prepare testing ends.3/5/2009 8:47:58 AM -- Dispatching transactions begins ...3/5/2009 8:47:58 AM -- Database cache settings: (minimum: 128.0 MB, maximum: 1.0 GB)3/5/2009 8:47:58 AM -- Database flush thresholds: (start: 10.2 MB, stop: 20.5 MB)3/5/2009 8:48:03 AM -- Database read latency thresholds: (average: 0.02 seconds/read, maximum: 0.05 seconds/read).3/5/2009 8:48:03 AM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.05 seconds/write).3/5/2009 8:48:05 AM -- Operation mix: Sessions 12, Inserts 25%, Deletes 10%, Replaces 50%, Reads 15%, Lazy Commits 80%.3/5/2009 8:48:05 AM -- Performance logging begins (interval: 15000 ms).3/5/2009 8:48:05 AM -- Attaining prerequisites:3/5/2009 8:54:13 AM -- \Database(JetstressWin)\Database Cache Size, Last: 968089600.0 (lower bound: 966367600.0, upper bound: none)3/5/2009 10:54:15 AM -- Performance logging ends.3/5/2009 10:54:15 AM -- JetInterop batch transaction stats: 57614, 56979, 57398, and 57460.3/5/2009 10:54:16 AM -- Dispatching transactions ends.3/5/2009 10:54:16 AM -- Shutting down databases ...3/5/2009 10:54:35 AM -- Instance2304.1 (complete), Instance2304.2 (complete), Instance2304.3 (complete), and Instance2304.4 (complete)3/5/2009 10:54:35 AM -- Performance logging begins (interval: 15000 ms).3/5/2009 10:54:35 AM -- Verifying database checksums ...3/5/2009 11:33:36 AM -- M: (100% processed), N: (100% processed), O: (100% processed), and P: (100% processed)3/5/2009 11:33:37 AM -- Performance logging ends.3/5/2009 11:33:37 AM -- C:\Data\Jetstress\DBChecksum_2009_3_5_10_54_35.blg has 156 samples.3/5/2009 11:33:43 AM -- C:\Data\Jetstress\DBChecksum_2009_3_5_10_54_35.html is saved.3/5/2009 11:33:43 AM -- Verifying log checksums ...3/5/2009 11:33:48 AM -- L:\01 (22 logs passed), L:\02 (22 logs passed), L:\03 (22 logs passed), and L:\04 (22 logs passed)3/5/2009 11:33:48 AM -- C:\Data\Jetstress\Performance_2009_3_5_8_48_3.blg has 504 samples.3/5/2009 11:33:48 AM -- Creating test report ...3/5/2009 11:33:54 AM -- Volume M: has 0.0161 for Avg. Disk sec/Read.3/5/2009 11:33:54 AM -- Volume N: has 0.0167 for Avg. Disk sec/Read.3/5/2009 11:33:54 AM -- Volume O: has 0.0153 for Avg. Disk sec/Read.3/5/2009 11:33:54 AM -- Volume P: has 0.0173 for Avg. Disk sec/Read.3/5/2009 11:33:54 AM -- Volume L: has 0.0051 for Avg. Disk sec/Write.3/5/2009 11:33:54 AM -- Volume L: has 0.0000 for Avg. Disk sec/Read.3/5/2009 11:33:54 AM -- Test has 0 Maximum Database Page Fault Stalls/sec.3/5/2009 11:33:54 AM -- Test has 0 Database Page Fault Stalls/sec samples higher than 0.3/5/2009 11:33:54 AM -- C:\Data\Jetstress\Performance_2009_3_5_8_48_3.xml has 479 samples queried.Microsoft Exchange Server Jetstress
- Test Result Report

Intel® 1800 Mailbox

Exchange Server 2007

Storage Solution

Intel® Server Chassis SC5400 and Server

Board S5000PSL

Tested with: ESRP – Storage Version 2.1, Windows Server 2003 R2

Tested Date: March 6, 2009

Publish Date: September 7, 2009

Summary of content (20 pages)

PAGE 1
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Tested with: ESRP – Storage Version 2.
PAGE 2
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL DISCLAIMER The information contained in this document is provided for informational purposes only and represents the current view of Intel® Corporation (“Intel”) and its contributors ("Contributors") on, as of the date of publication.
PAGE 3
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Contents Hardware Components.........................................................................................................................4 Software Components..........................................................................................................................4 Introduction............................................................................................
PAGE 4
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Hardware Components Quantity Item One Intel® Server Board One Intel Server Chassis Manufacturer Intel Intel SC5400. Additional information is available at: http://www.intel.com/products/server/chassis/sc5400/sc5400overview.htm. ® SRCSASJV. Additional information is available at: http://www.intel.com/products/server/raid-controllers/srcsasjv/srcsasjvoverview.htm.
PAGE 5
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Introduction This document provides information on Intel’s storage solution for Microsoft Exchange Server 2007, based the Microsoft Exchange Solution Reviewed Program (ESRP) – Storage program*.
PAGE 6
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL For more information on identifying and addressing performance bottlenecks in an Exchange system, please refer to Microsoft's Troubleshooting Microsoft Exchange Server Performance, available at http://go.microsoft.com/fwlink/?LinkId=23454. Test Server Configuration Component Description Server Chassis Intel® SC5400 Server Board Intel® S500PSL CPU 2 Intel® Xeon® E5320, quad-core, 1.
PAGE 7
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Tested Deployment The following tables summarize the testing environment: Description Data Number of Exchange mailboxes simulated 1800 Number of hosts 1 Number of storage groups / host 4 Number of mailbox stores / storage group 1 Number of mailboxes / mailbox store 450 Number of mailbox store LUNs / storage group 1 Simulated profile: I/O’s per second per mailbox 0.
PAGE 8
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Primary Storage Software Component Description HBA driver Intel® SRCSASRB HBA Queue Target Setting N/A HBA Queue Depth Setting N/A Multi-Pathing N/A Host OS MS Windows Server 2003 R2 Enterprise x64 Edition w/ Service Pack 1 ESE.dll file version 08.00.0685.
PAGE 9
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Best Practices Exchange Server is a disk-intensive application. Based on the testing runs using the ESRP framework, we recommend the following Microsoft best practices for storage system design for Exchange Server 2007, available at: http://technet.microsoft.com/en-us/library/bb124518.aspx.
PAGE 10
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL I/O Component Metric Database I/O Average Database Disk Transfers/sec 122.227 Average Database Disk Reads/sec 127.296 Average Database Disk Writes/sec 117.158 Average Database Disk Read Latency (ms) 0.016 Average Database Disk Write Latency (ms) 0.019 Transaction Log I/O Average Log Disk Writes/sec 188.959 Average Log Disk Write Latency (ms) 0.
PAGE 11
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Appendix A - Test Results Microsoft Exchange Server Jetstress 24 Hour Reliability Microsoft Exchange Server Jetstress Stress Test Result Report Test Summary Overall Test Result Pass Machine Name DMRTK-SRVR-I2 Test Description Intel® SRCSASRB mailboxes=1800, size=250, IOPS=0.
PAGE 12
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Delete operations 10% Replace operations 50% Read operations 15% Lazy commits 80% Disk Subsystem Performance LogicalDisk Avg. Disk sec/Read Avg. Disk sec/Write Disk Reads/sec Disk Writes/sec Avg. Disk Bytes/Write Database (M:) 0.016 0.019 126.901 122.467 (n/a) Database (N:) 0.017 0.019 127.072 115.989 (n/a) Database (O:) 0.015 0.019 127.478 116.
PAGE 13
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/6/2009 7:47:44 PM -- JetInterop batch transaction stats: 569497, 569587, 570316, and 570129. 3/6/2009 7:48:47 PM -- Dispatching transactions ends. 3/6/2009 7:48:47 PM -- Shutting down databases ... 3/6/2009 9:24:10 PM -- Instance2840.1 (complete), Instance2840.2 (complete), Instance2840.3 (complete), and Instance2840.
PAGE 14
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress Test Result Report Checksum Statistics - All Database Seen pages Bad pages Correctable pages Wrong page no pages File length / seconds taken M:\Jetstress1.edb 17813464 0 0 0 139167 MBytes / 2371 seconds N:\Jetstress1.edb 17813472 0 0 0 139167 MBytes / 2780 seconds O:\Jetstress1.edb 17813472 0 0 0 139167 MBytes / 2668 seconds P:\Jetstress1.
PAGE 15
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/5/2009 7:41:32 PM -- Database flush thresholds: (start: 10.2 MB, stop: 20.5 MB) 3/5/2009 7:41:37 PM -- Database read latency thresholds: (average: 0.02 seconds/read, maximum: 0.1 seconds/read). 3/5/2009 7:41:37 PM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.1 seconds/write).
PAGE 16
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress 2 Hour Performance Microsoft Exchange Server Jetstress Performance Test Result Report Test Summary Overall Test Result Pass Machine Name DMRTK-SRVR-I2 Test Description Intel® SRCSASRB mailboxes=1800, size=250, IOPS=0.
PAGE 17
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Disk Subsystem Performance LogicalDisk Avg. Disk sec/Read Avg. Disk sec/Write Disk Reads/sec Disk Writes/sec Avg. Disk Bytes/Write Database (M:) 0.016 0.020 137.238 123.295 (n/a) Database (N:) 0.017 0.019 136.878 121.694 (n/a) Database (O:) 0.015 0.020 137.248 123.954 (n/a) Database (P:) 0.017 0.020 138.488 124.237 (n/a) Log (L:) 0.000 0.005 0.000 212.
PAGE 18
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/5/2009 10:54:35 AM -- Performance logging begins (interval: 15000 ms). 3/5/2009 10:54:35 AM -- Verifying database checksums ... 3/5/2009 11:33:36 AM -- M: (100% processed), N: (100% processed), O: (100% processed), and P: (100% processed) 3/5/2009 11:33:37 AM -- Performance logging ends. 3/5/2009 11:33:37 AM -- C:\Data\Jetstress\DBChecksum_2009_3_5_10_54_35.blg has 156 samples.
PAGE 19
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress Test Result Report Checksum Statistics - All Database Seen pages Bad pages Correctable pages Wrong page no pages File length / seconds taken M:\Jetstress1.edb 14956658 0 0 0 116848 MBytes / 1985 seconds N:\Jetstress1.edb 14957426 0 0 0 116854 MBytes / 2340 seconds O:\Jetstress1.edb 14956658 0 0 0 116848 MBytes / 2204 seconds P:\Jetstress1.
PAGE 20
Intel® 1800 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/5/2009 8:47:58 AM -- Database flush thresholds: (start: 10.2 MB, stop: 20.5 MB) 3/5/2009 8:48:03 AM -- Database read latency thresholds: (average: 0.02 seconds/read, maximum: 0.05 seconds/read). 3/5/2009 8:48:03 AM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.05 seconds/write).
