Microsoft Exchange Server Jetstress
- Stress Test Result Report
3/20/2009 9:06:45 AM -- Jetstress testing begins ...3/20/2009 9:06:45 AM -- Prepare testing begins ...3/20/2009 9:06:46 AM -- Attaching databases ...3/20/2009 9:06:46 AM -- Prepare testing ends.3/20/2009 9:06:46 AM -- Dispatching transactions begins ...3/20/2009 9:06:46 AM -- Database cache settings: (minimum: 32.0 MB, maximum: 256.0 MB)3/20/2009 9:06:46 AM -- Database flush thresholds: (start: 2.6 MB, stop: 5.1 MB)3/20/2009 9:06:48 AM -- Database read latency thresholds: (average: 0.02 seconds/read, maximum: 0.1 seconds/read).3/20/2009 9:06:48 AM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.1 seconds/write).3/20/2009 9:06:49 AM -- Operation mix: Sessions 3, Inserts 25%, Deletes 10%, Replaces 50%, Reads 15%, Lazy Commits 80%.3/20/2009 9:06:49 AM -- Performance logging begins (interval: 15000 ms).3/20/2009 9:06:49 AM -- Attaining prerequisites:3/20/2009 9:16:10 AM -- \Database(JetstressWin)\Database Cache Size, Last: 241655800.0 (lower bound: 241591900.0, upper bound: none)3/21/2009 9:16:12 AM -- Performance logging ends.3/21/2009 9:16:12 AM -- JetInterop batch transaction stats: 381237.3/21/2009 9:16:12 AM -- Dispatching transactions ends.3/21/2009 9:16:12 AM -- Shutting down databases ...3/21/2009 9:16:49 AM -- Instance2700.1 (complete)3/21/2009 9:16:49 AM -- Performance logging begins (interval: 15000 ms).3/21/2009 9:16:49 AM -- Verifying database checksums ...3/21/2009 9:46:33 AM -- M: (100% processed)3/21/2009 9:46:34 AM -- Performance logging ends.3/21/2009 9:46:34 AM -- C:\Data\Jetstress\DBChecksum_2009_3_21_9_16_49.blg has 118 samples.3/21/2009 9:46:37 AM -- C:\Data\Jetstress\DBChecksum_2009_3_21_9_16_49.html is saved.3/21/2009 9:46:37 AM -- Verifying log checksums ...3/21/2009 9:46:38 AM -- L:\01 (22 logs passed)3/21/2009 9:46:38 AM -- C:\Data\Jetstress\Stress_2009_3_20_9_6_48.blg has 5797 samples.3/21/2009 9:46:38 AM -- Creating test report ...3/21/2009 9:47:30 AM -- Volume M: has 0.0170 for Avg. Disk sec/Read.3/21/2009 9:47:30 AM -- Volume L: has 0.0008 for Avg. Disk sec/Write.3/21/2009 9:47:30 AM -- Volume L: has 0.0000 for Avg. Disk sec/Read.3/21/2009 9:47:30 AM -- Test has 0 Maximum Database Page Fault Stalls/sec.3/21/2009 9:47:30 AM -- Test has 0 Database Page Fault Stalls/sec samples higher than 0.3/21/2009 9:47:30 AM -- C:\Data\Jetstress\Stress_2009_3_20_9_6_48.xml has 5759 samples queried.
Microsoft Exchange Server Jetstress
- Test Result Report
Microsoft Exchange Server Jetstress 2 Hour Performance
Microsoft Exchange Server Jetstress
- Performance Test Result Report
Microsoft Exchange Server Jetstress
- Test Result Report

Intel® 550 Mailbox

Exchange Server 2007

Storage Solution

Intel® Server Chassis SC5400 and Server

Board S5000PSL

Tested with: ESRP – Storage Version 2.1, Windows Server 2003 R2

Tested Date: March 21, 2009

Publish Date: September 7, 2009

Summary of content (20 pages)

PAGE 1
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Tested with: ESRP – Storage Version 2.
PAGE 2
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL DISCLAIMER The information contained in this document is provided for informational purposes only and represents the current view of Intel® Corporation (“Intel”) and its contributors ("Contributors") on, as of the date of publication.
PAGE 3
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Contents Hardware Components.........................................................................................................................4 Software Components..........................................................................................................................4 Introduction............................................................................................
PAGE 4
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Hardware Components Quantity Item Manufacturer ® One Intel Server Board One Intel Server Chassis Intel S5000PSL. Additional information is available at: http://www.intel.com/products/server/motherboards/s5000psl/s5000psloverview.htm. Intel SC5400. Additional information is available at: http://www.intel.com/products/server/chassis/sc5400/sc5400overview.htm.
PAGE 5
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Introduction This document provides information on Intel’s storage solution for Microsoft Exchange Server 2007, based the Microsoft Exchange Solution Reviewed Program (ESRP) – Storage program*.
PAGE 6
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL For more information on identifying and addressing performance bottlenecks in an Exchange system, please refer to Microsoft's Troubleshooting Microsoft Exchange Server Performance, available at http://go.microsoft.com/fwlink/?LinkId=23454. Test Server Configuration Component Description Server Chassis Intel® SC5400 Server Board Intel® S500PSL CPU 2 Intel® Xeon® E5320, quad-core, 1.
PAGE 7
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Tested Deployment The following tables summarize the testing environment: Description Data Number of Exchange mailboxes simulated 550 Number of hosts 1 Number of storage groups / host 1 Number of mailbox stores / storage group 1 Number of mailboxes / mailbox store 550 Number of mailbox store LUNs / storage group 1 Simulated profile: I/O’s per second per mailbox 0.
PAGE 8
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Primary Storage Software Component Description HBA driver Intel SRCSASRB HBA Queue Target Setting N/A HBA Queue Depth Setting N/A Multi-Pathing N/A Host OS MS Windows Server 2003 R2 Enterprise x64 Edition w/ Service Pack 1 ESE.dll file version 08.00.0685.
PAGE 9
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Best Practices Exchange Server is a disk-intensive application. Based on the testing runs using the ESRP framework, we recommend the following Microsoft best practices for storage system design for Exchange Server 2007, available at: http://technet.microsoft.com/en-us/library/bb124518.aspx.
PAGE 10
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL I/O Component Metric Database I/O Average Database Disk Transfers/sec 79.978 Average Database Disk Reads/sec 84.697 Average Database Disk Writes/sec 75.259 Average Database Disk Read Latency (ms) 0.017 Average Database Disk Write Latency (ms) 0.088 Transaction Log I/O Average Log Disk Writes/sec 49.026 Average Log Disk Write Latency (ms) 0.
PAGE 11
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Appendix A - Test Results Microsoft Exchange Server Jetstress 24 Hour Reliability Microsoft Exchange Server Jetstress Stress Test Result Report Test Summary Overall Test Result Pass Machine Name DMRTK-SRVR-I2 Test Description Intel SRCSASRB 4-SATA drives, mailboxes=0550, size=250, IOPS=0.
PAGE 12
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Replace operations 50% Read operations 15% Lazy commits 80% Disk Subsystem Performance LogicalDisk Avg. Disk sec/Read Avg. Disk sec/Write Disk Reads/sec Disk Writes/sec Avg. Disk Bytes/Write Database (M:) 0.017 0.088 84.697 75.259 (n/a) Log (L:) 0.000 0.001 0.000 49.026 10357.696 Host System Performance Counter Average Minimum Maximum % Processor Time 0.210 0.000 2.
PAGE 13
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL samples. 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 3/21/2009 queried. 9:46:37 9:46:37 9:46:38 9:46:38 9:46:38 9:47:30 9:47:30 9:47:30 9:47:30 9:47:30 9:47:30 AM AM AM AM AM AM AM AM AM AM AM ------------ C:\Data\Jetstress\DBChecksum_2009_3_21_9_16_49.html is saved. Verifying log checksums ...
PAGE 14
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress Test Result Report Checksum Statistics - All Database Seen pages Bad pages Correctable pages Wrong page File length / no pages seconds taken M:\01\Jetstress1.edb 19704210 0 0 0 153939 MBytes / 1783 seconds (Sum) 0 0 153939 MBytes / 1783 seconds 19704210 0 Disk Subsystem Performance (of checksum) LogicalDisk Avg. Disk sec/Read Avg.
PAGE 15
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/20/2009 9:06:49 AM -- Attaining prerequisites: 3/20/2009 9:16:10 AM -- \Database (JetstressWin)\Database Cache Size, Last: 241655800.0 (lower bound: 241591900.0, upper bound: none) 3/21/2009 9:16:12 AM -- Performance logging ends. 3/21/2009 9:16:12 AM -- JetInterop batch transaction stats: 381237. 3/21/2009 9:16:12 AM -- Dispatching transactions ends.
PAGE 16
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress 2 Hour Performance Microsoft Exchange Server Jetstress Performance Test Result Report Test Summary Overall Test Result Pass Machine Name DMRTK-SRVR-I2 Test Description Intel SRCSASRB 4-SATA drives, mailboxes=0550, size=250, IOPS=0.
PAGE 17
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Lazy commits 80% Disk Subsystem Performance LogicalDisk Avg. Disk sec/Read Avg. Disk sec/Write Disk Reads/sec Disk Writes/sec Avg. Disk Bytes/Write Database (M:) 0.017 0.090 85.181 82.710 (n/a) Log (L:) 0.000 0.001 0.000 56.431 10405.428 Host System Performance Counter Average Minimum Maximum % Processor Time 0.225 0.052 0.495 Available MBytes 3135.921 3133.
PAGE 18
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/19/2009 8:21:25 PM -- Attaining prerequisites: 3/19/2009 8:30:44 PM -- \Database(JetstressWin)\Database Cache Size, Last: 242278400.0 (lower bound: 241591900.0, upper bound: none) 3/19/2009 10:30:45 PM -- Performance logging ends. 3/19/2009 10:30:45 PM -- JetInterop batch transaction stats: 39901. 3/19/2009 10:30:46 PM -- Dispatching transactions ends.
PAGE 19
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL Microsoft Exchange Server Jetstress Test Result Report Checksum Statistics - All Database Seen pages Bad pages Correctable pages Wrong page File length / no pages seconds taken M:\01\Jetstress1.edb 17801090 0 0 0 139071 MBytes / 1599 seconds (Sum) 0 0 139071 MBytes / 1599 seconds 17801090 0 Disk Subsystem Performance (of checksum) LogicalDisk Avg. Disk sec/Read Avg.
PAGE 20
Intel® 550 Mailbox Exchange Server 2007 Storage Solution Intel® Server Chassis SC5400 and Server Board S5000PSL 3/19/2009 8:21:24 PM -- Log write latency thresholds: (average: 0.01 seconds/write, maximum: 0.05 seconds/write). 3/19/2009 8:21:25 PM -- Operation mix: Sessions 3, Inserts 25%, Deletes 10%, Replaces 50%, Reads 15%, Lazy Commits 80%. 3/19/2009 8:21:25 PM -- Performance logging begins (interval: 15000 ms).
