Quickstart Guide English ( 3 – 7 ) Guía de inicio rápido Español ( 8 – 12 ) Guide d'utilisation rapide Français ( 13 – 17 ) Guida rapida Italiano ( 18 – 22 ) Schnellstart-Anleitung Deutsch ( 23 – 27 ) Snelstartgids Nederlands ( 28 – 32 ) Appendix English ( 34 )
Quickstart Guide (English) Introduction Box Contents Pathfinder Microphone with Cable 1/8” (3.5 mm) Stereo Aux Cable Power Cable Quickstart Guide Safety & Warranty Manual Support For the latest information about this product (system requirements, compatibility information, etc.) and product registration, visit ionaudio.com. Rechargeable Batteries Rechargeable lead-acid batteries are the same type used in automobiles.
Outdoor Use and Care Though Pathfinder is water-resistant and able to tolerate splashing water, please review the tips below to get the best performance from Pathfinder: • Pathfinder must only be used outdoors with power outlets or extension cords that are rated for outdoor use. • Bring Pathfinder indoors during extreme weather. • Please do not place Pathfinder in standing water. • Please do not connect the power cable to Pathfinder in a wet environment.
Features 1. Power Button: Turns Pathfinder on or off. Please note that while Pathfinder is connected to a power source, it does not need to be powered on to charge the battery. When the power is on, the display will show the power indicator. 11 12 10 1 8 2 3 10 6 7 9 4 2. Bluetooth Button: Press the Bluetooth button to disconnect a paired Bluetooth device. 5 3. Light Mode Button: Press this button to select how the lights on the front panel function: • White: The lights are lit solidly white.
10. Microphone Input with Volume Control (1/4”): This mono input accepts a 1/4” (6.35 mm) input such as a microphone, guitar, or other musical instrument. 11. Auxiliary Input: This stereo 1/8” (3.5 mm) input can be used to connect a CD player, MP3 player, or other audio source. 12. USB Charging Ports: Connect your device’s charge cable here to charge it. USB charging only functions when the unit’s power is turned on. Note: To charge smartphones and tablets faster, put the device’s screen to sleep. 13.
Troubleshooting If the sound is distorted: Try lowering the volume control of your sound source, musical instrument, or microphone. Also, try to reduce the overall volume of Pathfinder using the Master Volume knob. If there is too much bass: Try adjusting the tone or EQ control on your sound source to lower the bass level. This will allow you to play the music louder before clipping (distortion) occurs. If there is a high-pitched whistling noise when using microphones: This is probably feedback.
Guía de inicio rápido (Español) Introducción Contenido de la caja Pathfinder Micrófono y cable Cable auxiliar estéreo de 3,5 mm (1/8 pulg.) Cable de alimentación Guía de inicio rápido Manual sobre la seguridad y garantía Soporte Para obtener la información más completa acerca de este product (los requisitos del sistema, compatibilidad, etc) y registro del producto, visite ionaudio.com. Baterías recargables Las baterías de plomo-ácido recargables son del mismo tipo que se usa en los automóviles.
Uso y cuidado a la intemperie Aunque el Pathfinder es resistente al agua y capaz de tolerar salpicaduras, lea las sugerencias que se incluyen a continuación para obtener el mejor rendimiento del Pathfinder: • El Pathfinder sólo puede usarse en exteriores con tomas de corriente o cables de prolongación aptos para el uso en exteriores. • Traiga a los Pathfinder bajo techo durante condiciones meteorológicas extremas. • No coloque el Pathfinder sobre agua estancada.
Características 1. Botón de encendido: Enciende y apaga el Pathfinder. Tenga en cuenta que mientras el Pathfinder está conectado a un suministro eléctrico, no es necesario encenderlo para que cargue la batería. Cuando el altavoz está encendido, la pantalla mostrará el indicador de encendido. 11 12 10 1 8 2 3 10 6 7 9 4 2. Botón de Bluetooth: Pulse el botón Bluetooth para desconectar un dispositivo Bluetooth apareado. 5 3.
9. Control de volumen maestro: Este control ajusta el volumen de la mezcla principal del altavoz, que incluye la entrada de micrófono, la entrada auxiliar, el sintonizador y el audio de un dispositivo Bluetooth apareado. 10. Micrófono con control de volumen (6,35 mm): Esta entrada mono admite una entrada de 6,35 mm (1/4 pulg.) tal como un micrófono, una guitarra u otro instrumento musical. 11. Entrada auxiliar: Esta entrada de 3,5 mm (1/8 pulg.
Solución de problemas Si el sonido está distorsionado: Pruebe bajando el control de volumen de su fuente de sonido, instrumento musical o micrófono. Pruebe también reduciendo el volumen general del Pathfinder utilizando la perilla de volumen maestro. Si hay demasiados graves: Intente ajustando el control de tono o ecualización de su fuente de sonido para reducir el nivel de graves. De esta forma podrá reproducir la música con más volumen antes de que se produzca el recorte (distorsión).
Guide d'utilisation rapide (Français) Présentation Contenu de la boîte Pathfinder Microphone et câble Câble auxiliaire stéréo 3,5 mm Câble d'alimentation Guide d'utilisation rapide Consignes de sécurité et informations concernant la garantie Assistance Pour les dernières informations concernant ce produit (la configuration système minimale requise, la compatibilité, etc) et l'enregistrement du produit, veuillez visitez le site ionaudio.com.
Utilisation extérieure et entretien Bien que le Pathfinder soit résistant à l'eau et tolère les éclaboussures, les conseils ci-dessous qui vous permettront de tirer le maximum de votre Pathfinder : • L’enceinte Pathfinder doit être utilisée à l’extérieur uniquement avec une prise secteur ou un câble prolongateur qui sont conçus pour une utilisation extérieure. • L’enceinte Pathfinder doit être rentrée à l'intérieur lors de conditions météorologiques extrêmes.
Caractéristiques 1. Touche d'alimentation : Permet de mettre le Pathfinder sous et hors tension Veuillez noter que lorsque le Pathfinder est branché à une source d’alimentation, il peut recharger la pile sans être sous tension. Lorsque l'appareil est sous tension, l'écran affiche l'indicateur d'alimentation. 2. Touche Bluetooth : Appuyez sur le bouton Bluetooth du pour déconnecter le périphérique Bluetooth branché. 11 12 10 1 8 2 3 10 6 7 9 4 5 3.
9. Volume général : Ce bouton permet de régler le volume du mix général qui comprend l'entrée microphone, l’entrée auxiliaire, le syntoniseur et l'audio d'un périphérique Bluetooth jumelé. 10. Microphone avec commande de volume (1/4 po) : Cette entrée mono peut accueillir un câble de 6,35 mm (1/4 po) pour microphone, guitare ou un autre instrument de musique. 11. Entrée auxiliaire : Cette entrée stéréo 3,5mm (1/8 po) po permettent de brancher un smartphone, un lecteur MP3 ou autres sources audio. 12.
Guide de dépannage Lorsqu’il y a de la distorsion : Essayez de diminuer le volume du périphérique audio, de l’instrument de musique ou du microphone. Essayez également de réduire le volume général de l’enceinte Pathfinder. Lorsqu’il y a trop de basses fréquences : Essayez de régler le niveau de tonalité et d’égalisation sur l’appareil de source d’entrée audio afin de diminuer le niveau des basses fréquences. Cela vous permettra d'augmenter le volume de la musique avant que l'écrêtage se produise.
Guida rapida (Italiano) Introduzione Contenuti della confezione Pathfinder Microfono e cavo Cavo aux stereo da 3,5 mm Cavo di alimentazione Guida rapida Istruzioni di sicurezza e garanzia Assistenza Per conoscere le ultime informazioni in merito a questo prodotto (i requisiti di sistema complete, compatibilità, ecc) e per la registrazione del prodotto, recarsi alla pagina ionaudio.com.
Utilizzo all'aperto e cura Sebbene il Pathfinder sia impermeabile e in grado di sopportare eventuali schizzi d'acqua, leggere attentamente i consigli di cui sotto per ottenere le migliori prestazioni dal Pathfinder: • Il Pathfinder deve essere utilizzato unicamente all'aperto, con prese di alimentazione o prolunghe dalla tensione nominale specifica per un utilizzo all'aperto. • Portare il Pathfinder all'interno in caso di maltempo. • Non collocare il Pathfinder in acqua.
Caratteristiche 1. Tasto di alimentazione: accende o spegne il Pathfinder. Va notato che quando il Pathfinder è collegato ad una fonte di alimentazione, non deve essere necessariamente acceso per caricare la batteria. Quando l'alimentazione è accesa, a display compare l'indicatore di alimentazione. 2. Tasto Bluetooth: Premere il pulsante tasto Bluetooth per scollegare di un dispositivo Bluetooth accoppiato. 11 12 10 1 8 2 3 10 6 7 9 4 5 3.
9. Comando volume Master: questo comando regola il volume principale di mix dell'altoparlante, che comprende l'ingresso microfono, l'ingresso ausiliario (aux), il sintonizzatore e l'audio di un dispositivo Bluetooth accoppiato. 10. Microfono con controllo di guadagno volume (1/4"): questo ingresso mono accetta un ingresso da 6,35 mm (1/4") quali un microfono, chitarra o altro strumento musicale. 11.
Risoluzione di problemi Il suono è distorto: provare ad abbassare il volume della propria fonte audio, dello strumento musicale o del microfono. Inoltre, provare a ridurre il volume complessivo del Pathfinder utilizzando la manopola Volume Master. Eccessivi bassi: provare a regolare la tonalità o il comando EQ a livello della fonte audio per abbasare il livello dei bassi. Ciò permetterà di suonare la musica più forte prima che salti (che si verifichi distorsione).
Schnellstart-Anleitung (Deutsch) Einführung Lieferumfang Pathfinder Mikrofon und Kabel 3,5 mm Stereo Aux-Kabel Netzkabel Schnellstart-Anleitung Sicherheitshinweise und Garantieinformationen Kundendienst Für aktuelledie neuesten Informationen zu diesem Produkt (Systemanforderungen, Informationen zur Kompatibilität etc.) und zur Produktregistrierung besuchen Sie ionaudio.com.
Einsatz im Freien und Pflege des Produkts Obwohl der Pathfinder wasserfest ist und Wasserspritzer vertragen kann, lesen Sie bitte die folgenden Tipps für die optimale Performance Ihres Pathfinder: • Pathfinder darf im Freien nur mit Steckdosen oder Verlängerungskabeln verwendet werden, die für den Einsatz im Freien geeignet sind. • Bringen Sie Pathfinder bei extremen Wetterbedingungen ins Haus. • Bitte platzieren Sie den Pathfinder nie instehenden Gewässern.
Funktionen 1. Power-Taste: Schaltet den Pathfinder an oder aus. Beachten Sie bitte, dass beim Anschluss des Pathfinder an ein Stromnetz das Gerät nicht eingeschaltet werden muss, um die Batterie aufzuladen. Wenn das Gerät eingeschaltet ist, zeigt das Display das Netzanzeige an. 2. Bluetooth-Taste: Drücken Sie die Taste Bluetooth, um ein angeschlossenes Bluetooth-Gerät zu trennen. 11 12 10 1 8 2 3 10 6 7 9 4 5 3.
10. Mikrofon Eingang mit Lautstärke-Regler (6,35 mm Klinke): Dieser Mono Eingang ist kompatibel mit normalen Klinkenkabeln von einem Mikrofon, einer Gitarre oder einem anderen Musikinstrument. 11. AUX-Eingang: Dieser 3,5mm (1/8”) Stereo-Eingang kann dazu verwendet werden, einen Smartphone, einen MP3-Player oder eine andere Audio-Quelle anzuschließen. 12. USB-Anschlüsse: Schließen Sie das Ladekabel Ihres Geräts hier an, um es aufzuladen. Das Laden via USB funktioniert nur, wenn das Gerät eingeschaltet ist.
Fehlerbehebung Der Ton klingt verzerrt: Drehen Sie den Lautstärkeregler an Ihrer Tonquelle, dem Musikinstrument oder dem Mikrofon zurück. Versuchen Sie auch, die Gesamtlautstärke von Pathfinder mit dem Gesamtlautstärkeregler zu reduzieren. Zu viel Bass: Versuchen Sie, den Ton- oder EQ-Regler Ihrer Tonquelle anzupassen, um den Bass zu verringern. Dies ermöglicht Ihnen, die Musik lauter abzuspielen, bevor der Klang verzerrt.
Snelstartgids (Nederlands) Introductie Inhoud van de doos Pathfinder Microfoon en kabel Stereo aux-kabel van 3,5 mm Stroomkabel Snelstartgids Veiligheids-en garantie handleiding Ondersteuning Voor de laatste informatie over dit product (systeemvereisten, compatibiliteitsinformatie, enz.) en productregistratie, bezoek ionaudio.com. Herlaadbare accu's Oplaadbare loodzwavelzuuraccu's zijn van hetzelfde type dat gebruikt wordt in auto's.
Gebruik buitenshuis en onderhoud Hoewel de Pathfinder waterbestendig is en bestand is tegen opspattend water, vragen wij u toch de tips hieronder te volgen voor optimale prestaties van uw Pathfinder: • Pathfinder mag buiten alleen worden gebruikt met stopcontacten of verlengsnoeren die zijn goedgekeurd voor gebruik buitenshuis. • Breng de Pathfinder naar binnen bij slecht weer. • De Pathfinder niet plaatsen in stilstaand water. • Sluit in een natte omgeving de stroomkabel niet aan op de Pathfinder.
Kenmerken 1. Stroom-knop: Schakelt de Pathfinder in of uit. Opmerking: Wanneer de Pathfinder aangesloten is op een vermogensbron, hoeft deze niet ingeschakeld te zijn om de batterij te laten opladen. Wanneer het apparaat is ingeschakeld, verschijnt op het scherm de stroomindicator. 2. Bluetooth-knop: Druk op de knop Bluetooth verbreken om een gekoppeld Bluetooth-apparaat. 11 12 10 1 8 2 3 10 6 7 9 4 5 3.
10. Microfoon met volume-besturing (6,35 mm): Deze mono-ingang accepteert 6,35 mm (1/4")-input zoals microfoon, gitaar of andere muziekinstrumenten. 11. Aux-ingang: Deze stereo 3,5mm (1/8”) ingang kan worden gebruikt om een cd-speler, mp3-speler of andere geluidsbron te verbinden. 12. USB-poorten: Sluit hier de oplaadkabel van uw apparaat aan om het op te laden. Opladen met USB werkt alleen als het apparaat is ingeschakeld.
Problemen oplossen Het geluid is vervormd: Probeer de volumeknop van uw geluidsbron, muziekinstrument of microfoon te verlagen. Probeer ook om het hoofdvolume van de Pathfinder met de hoofdvolumeknop te verlagen. Er zijn teveel bassen: Probeer op de toon- of EQ-bedieningsknoppen aan uw geluidsbron het niveau van de lage tonen te verlagen. Dit stelt u in staat de muziek luider te zetten vooraleer “afgeknipte” (vervormde) klanken optreden.
Appendix (English) Technical Specifications Output Power 100 W (peak) Bluetooth Profiles: A2DP, AVRCP Range: Up to 100 feet / 30.5 meters * Water Resistant Class IPX4 Microphone Type Dynamic microphone recommended (included) Battery Type 12V, 7.0Ah SLA Battery Life Up to 75 hours ** Charge Port 2 USB, +5V, 1A Power Input Voltage: 110–240 VAC/VDC, 50/60 Hz Dimensions 11.0” x 18.0” x 18.5” 279 x 457 x 470 mm (width x depth x height) Weight 30.9 lbs.
ionaudio.com Manual Version 1.
