Specifications

Features

•

Vitreous china.

•

Drop-in

•

With overflow.

•

4" (102 mm) centers.

•

19-3/4" (502 mm) x 16-7/8" (429 mm)

Recommended Accessories

K-8998 P-Trap

CSA B651

Codes/Standards

ASME A112.19.2/CSA B45.1

ADA

ICC/ANSI A117.1

CSA B651

KOHLER

One-Year Limited Warranty

See website for detailed warranty information.

Available Color/Finishes

Color tiles intended for reference only.

DescriptionCodeColor

White0

Biscuit96

Almond47

DuneNY

Ice™ Grey95

SandbarG9

Mexican Sand™33

CashmereK4

Thunder™ Grey58

Black Black™7

USA/Canada: 1-800-4KOHLER (1-800-456-4537)

www.kohler.com

2-18-2015 03:22

Devonshire

Bathroom Sink

K-2279-4

PAGE 1
Devonshire® Bathroom Sink K-2279-4 Features • • • • • Vitreous china. Drop-in With overflow. 4" (102 mm) centers. 19-3/4" (502 mm) x 16-7/8" (429 mm) Recommended Accessories K-8998 P-Trap CSA B651 Codes/Standards ASME A112.19.2/CSA B45.1 ADA ICC/ANSI A117.1 CSA B651 KOHLER® One-Year Limited Warranty See website for detailed warranty information. Available Color/Finishes Color tiles intended for reference only. Color USA/Canada: 1-800-4KOHLER (1-800-456-4537) www.kohler.
PAGE 2
Devonshire® Bathroom Sink K-2279-4 4" (102 mm) Technical Information Notes All product dimensions are nominal. Installation: Drop-In Bowl area Length: 17" (432 mm) Width: 11" (279 mm) Water depth: 4-1/2" (114 mm) Number of deck holes: 3 Faucet hole(s): 1-1/4" (32 mm) Drain hole: 1-3/4" (44 mm) Template: Drop-in, 1002978-7, required, included NOTICE: Countertop manufacturer or cutter must use the cut-out template provided with the product, or a current one provided by Kohler Co. (call 1-800-4-KOHLER).
