Installation Guide
5
OPERATING YOUR FREEZER
Temperature Control
Once your freezer is in its proper place, plug the power cord into an electrical socket to turn on the unit.
NOTE:
If the unit is unplugged or loses power, you must wait 3 to 5 minutes before restarting the
unit. If you attempt to restart before this time delay, the freezer will not start.
Large amounts of food will lower the cooling efficiency of the appliance.
If you choose to change the thermostat setting, adjust thermostat control by one
numerical increment at a time. Allow several hours for tempe
rature to stabilize between
adjustments.
Defrosting Your Freezer
When? For the most efficient operation and minimum energy consumption, defrost the freezer
when the frost on the freezer walls is excessive or to inch thick (approximately every 3
months).
Choose a time when the stock of frozen food is low.
CAUTION
Do not use boiling water because it may damage the plastic parts. In addition, never
use a sharp or metallic instrument to remove frost as it may damage the cooling coils
and will void the warranty.
Remove the frozen food from the freezer and place it in a cooler to protect the food.
Unplug the freezer.
During defrosting, the ice melts into the cabinet.
Unscrew and remove the drain cap on th
e exterior front of the freezer (lower left).
Place a shallow pan outside drain outlet. The defrost water will drain out.
Check the pan occasionally so the water does not overflow.
If turning the freezer on for the first time, set the dial to "MAX" and allow 24 hours to pass before adjusting the
temperature to your needs. This will ensure the cabinet is thoroughly chilled before food is put in.
Your freezer will automatically maintain the temperature level you select. The interior temperature of
the freezer is adjusted through the thermostat knob. Rotate the thermostat knob clockwise and the interior
temperature will drop. The temperature control dial has 2 temperature settings and an OFF setting.
"MIN" is the cold setting, "MAX" is the coldest setting, "OFF" stands for stopping working.
Turning the temperature control to the "OFF" setting position stops the cooling cycle but doesn't shut off
the power of the freezer.
