Foodservice Solid Door Reach-ins Refrigerator Freezer Specification Sheet

ITEM NO. ______________________________________________________
PROJECT ______________________________________________________
LOCATION _____________________________________________________
DATE _________________________ QTY. ___________________________
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
CONSTRUCTION
• All stainless steel nish interior and
exterior
• Top mounted low prole interior
evaporator housing
• Digital thermometer on TAC models
(built into electronic controller
interface on TAF models)
• Electric condensate evaporator
• Heavy-duty casters
• Three heavy-duty, welded wire, gray
epoxy-coated shelves per section,
adjustable in 1/2" increments
• 2
1
/
2
" foamed-in-place “zero ODP”
urethane insulated walls
DOORS
• 2" stainless steel foamed-in-place doors
• Self-closing with cylinder locks and
90° hold-open feature
• Horizontal door handles
• Self-sealing replaceable magnetic
gaskets
• Lift-off doors
• Anti-condensate door frame heaters
• Light switch concealed in door hinge
• Door width:
TAC/TAF-27HDSA .............. 27
3
/
4
"
TAC/TAF-48HD/74HDSA ... 23
3
/
8
"
REFRIGERATION
• TAC model refrigerant: R-134a
• TAF model refrigerant: R-404A
• Top mounted, self-contained,
factory tested refrigeration system
• TAF models feature auto defrost with
double failsafe override
• Electric condensate evaporator
• TAC model temperature range:
34° to 41°F (1° to 5°C)
• TAF model temperature range:
0° to -20°F (-18° to -29°C)
• R-factor (insulation efciency
rating): 21.55 on walls, 17.24 on
doors
WARRANTY
• Standard limited four year extended
compressor and one year limited
parts and labor
FEATURES
TAF-48HDSA
TAC/TAF SERIES
Foodservice Solid Door
Reach-ins
OPTIONS
❑ Add sufx “R” for remote system
❑ Legs
❑ Pan rack
❑ Additional welded wire gray
epoxy shelving
REFRIGERATORS FREEZERS
❑ TAC-27HDSA ❑ TAF-27HDSA
❑ TAC-48HDSA ❑ TAF-48HDSA
❑ TAC-74HDSA ❑ TAF-74HDSA
STANDARD
ELECTRONIC CONTROL
ON TAF MODELS
• Allows user to easily monitor
defrost functions from the panel
interface on the front of the
merchandiser
• Audible and visual alarm
• Decreases service time and calls
• Eliminates room thermostat,
defrost termination/fan delay
control, defrost timer and digital
thermometer or other temperature
indicator
