Spec Sheet

Model:
Description:
Voltage:
Shipping Dimensions:
Unit Weight:
Shipping Weight:
MIM50-O
Maxx Ice 50lb Outdoor Ice Maker
120V/60Hz/1Ph, 220V/50Hz/1Ph
17” W x 26 3/4” D x 38” H
432mm W x 678mm D x 965mm H
Unit Dimensions:
14 5/8” W x 23 5/8” D x 33 1/2” H
371mm W x 600mm D x 851mm H
Ice Cube Size:
Power Consumption:
Ice Type:
3/4” x 3/4” x 1”
19mm x 19mm x 25mm
84 lb / 38 kg
Amps:
4.8
13.2kWh / 100lbs of ice
Slab Cube
93 lb / 42 kg
FEATURE LIST
October 2013
The compact MIM50-O produces up to 50 pounds of ice per day and includes a self-contained 25 pound
storage bin. The unit produces crystal clear ice cubes and features a stainless steel finish. Suitable for
freestanding or built in applications, this unit will run on standard household electrical current and is NSF
and UL approved for commercial use.
Model MIM50-O
Project Name:
Location:
Item:
Qty:
Model:
MAXX ICE
3355 Enterprise Avenue Fort Lauderdale, FL 33331
Tel: [phone] www.thelegacycompanies.com
Model MIM50-O
Outdoor Ice Maker
Maxx Ice’s continuing comitment to quality products may mean a change in specification or pricing without notice.
