Specifications

The EXTRIUM family
MCDI is introducing a new line of receivers with advanced
features such as IP reporting, reporting redundancy and
2 way voice to IP. The Extrium family is designed around
MCDI’S EXTRIUM board with embedded Linux and MCDI’S
Cognitum programming. This intelligent alarm receivers is
designed to fit a small form factor, withour mecanical parts prone to break. Several
models also have the ability to collect signals from legacy receivers and broadcast
them over IP.
Extrium::db is complete with internal database of 4000
accounts or linked to SECURITHOR software for unlimited
number of accounts. Extrium::db shows account informa-
tion, alarm codes in clear text, action to take according to
the complete list of info in the account. Ideal for stand alone
monitoring without PC.
Concentrator: Edb with cpu only (no internal receiver).
Manages inputs from traditional receivers or IP
panels and provides
D5: the workhorse of CMS! 6 lines, efficient
design in a one rack-mount space. No mechan-
ical part, redundancy management.
D6: horsepowers! 6 lines of a D5 + 2 way voice
to IP in only one rack-mount space. No more
costly PBX. Ideal to make PERS monitoring.
Available Q4 2012
MCDI Receivers: perfect choice for SECURITHOR
From low cost PCI board receivers to high end rack
mount Decrypta 6, MCDI receivers are the best fit for
your SECURITHOR.
MCDI receivers handle more than 20 alarm protocols such as Pulse, Contact
ID, SIA, Telim, Robofon and Tunstall TTnew. MCDI receivers are the best fit
for SECURITHOR has they are all made by the same manufacturer but MCDI
receivers will also work with most automation software on the market.
Efficient design
MCDI designed the Extrium box for models D3, EXSA and Extrium. This new box
is engineered so you can use your receiver either
desktop or in a PC chassis. Desk-
top units can be raised for easy
viewing or flat for stacking. D4
and Extrium units are made work
without prone to fail mecanical parts. They do not require fans in most condi-
tions and are made to work unattended.
Decrypta 5 and 6 are engineered to work in rack
chassis, without fan and to be serviced from the
front without stopping operation. Most components
are modular and easy to replace. With 6 lines per 1U
rackmount including 2 way voice operation, D5 and
D6 are real space savers for larger centrals.
pages 6 7
Exprecium D
MCDI introduced the concept of receivers on
PC board back in 1993. with the original TLR.
Exprecium D is now the 10th generation of MCDI
receivers boards. Exprecium was the first RoHS
compliant receivers on the market and Ed is the
3rd generation made with RoHS compliance. Chassis and power supply
provided by the host PC, Exprecium boards are lower cost alternative yet
not short on performance.
DECRYPTA 4 receiver
Based on legenday D2 and D3, D4 is the work
horse of Central stations and MCDIs most pop-
ular model. Easy to use, Easy to configure, it
packs over 20 alarm formats in a small form
factor.
Main features are 2 independant phone lines, 2 power inputs, dual report-
ing over serial or USB ports, front display for events viewing and configura-
tion.
Front display configuration menus in English, French, German, Portugese,
Russian and Spanish. PC configuration tool available in Arabic, English,
Farsi, French, German, Portugese, Russian and Spanish. Available as RoHS
or non RoHS.
RoHS compliance
MCDI is the first manufacturer to introduce RoHS compliant alarm
receivers manufactured without lead, cadmium and pbb). Noneless
than 6 models where RoHS compliant when this CEE directive came
into effect. All new MCDI designs are totally in compliance with RoHS
directive and offered with WEE recycling when returned to MCDI.
With China, Turkey and California adopting similar lead free regulation,
MCDI is not only a technology choice but also an ecological choice.
Ease of use
MCDI external receivers are made to work out of the box, without the need
of a technician. Configuration panels are easy to understand and simple.
Power redundancy
All MCDI models are designed to run on at
least 2 power sources including 12V bat-
teries. Some like D5 and Extrium even
have a third souce, an internal lithium-ion
rechargeable battery to add one hour of operation in case of emergency or
equipment maintenance.
Listen-in and 2 WAY voice integration with CMS software
Decrypta 6 units have the capacity to route audio signals from receivers
over IP to any SIP client. No more web of wires or coslty PBX! Coming in
2012.
Receiving alarms from IP panels
MCDI SP is working with several manufacturers to integrate alarm signals
from IP panels. Formats from Paradox, 3i, Roel, SIA DC-09 are integrated in
the Extrium::CPU and DB models.
¬¬
Complete specifications available from mcdi.com
