Specifications

www.mcdi.com
Technical
Specifications
Communications:
Exprecium D provides 2 RJ11 type jacks for telephone line connection.
Type: Pulse, DTMF, FSK
Reception Speed: 10, 20, 40 pps DR / CS
Handshake and Kiss-off: 1400Hz /2300Hz/2225Hz
Pulse Frequency: 1800Hz / 1900Hz
Telim//Robofon: 1180Hz / /1100Hz
Reception Formats supported:
Acron Radionics 6500
Ademco: Radionics extended
- Slow/Fast; Sescoa Slow, Super Fast
- Contact ID; Sescoa Standard
- Extended; SIA
- Express; Silent Knight Slow
- High Speed Stratel
FBI Super Fast Napco Point ID
Tunstall TTnew( EDr only) BFSK,CFSK, VFSK (E2 only)
3x1 3x1 extended
4x1 3x1 extended compressed 4x2
4x1 extended 4x1 extended compressed 4x2
4x2 Zero removed 3x1, 4x1, extended.
Optex’s Varitech C&K: Bell 103A2 or CCIT ( option)
For Germany and Scandinavia (option): Telim
All boards are delivered with Bell 103 on both lines. Please specify for Telim
Output
Exprecium D reports signal to PC in MCDI, MCDI Enhanced, Surgard MRL2/
MLR200 and Ademco 685 modes. While the card is sitting in computer’s
PCI or PCI-E slot, output is through USB and Serial ports that are fed back
to PC. USB output at the back with high retention connector, bracket
holder for serial port supplied. Selectable Main and secondary outputs.
Printer Output:
Exprecium D support Epson T Family POS printer through Serial or USB
connection. Designed for Epson T88V.
Event Logging when PC is absent:
EXPRECIUM stores last 4095 events at all time and can continue receiving
even when PC is down if second power input is used.
Power Requirements:
From computer +12V Supply: 200 mA max.
From 6V Battery (standby): 200 mA
Station Requirements:
PC chassis with 12V electrical supply though PCI or PCI-E bus with full length
PCI or extenal 12Vdc power supply
Signal: USB 1.1/2.0 or Serial port.
Configuration tool : PC runing OS allowing installation of .NET 3.5 such as
Windows XP,Server 2003, Vista, Server 2008, Windows SMS, Windows 7
Battery Back-up:
EXPRECIUM D normal power source is the PC. A second power input is pro-
vided at the rear bracket allowing connection of an external battery. Battery
level supervised without charging. Battery must supply 7.2V 200ma
Monitoring Software:
Exprecium is compatible with most Automation software on the market
including SECURITHOR, SAMM X, WINSAMM, ABM, A-traq, Bykom, Central-
works, FROUROS II, Patriot, SIS, SIMS, and Softgard.
Multi-language configurator and traffic viewer
Comprehensive configuration tool in English with translations in Arabic,
Deutsch, Español, Farsi, Portugese and Russian.
Traffic viewer for PC and log
file included. Traffic viewer allows sending main output to Automation soft-
ware while secondary output trasmits to viewer for log writing.
STM SECURITHOR Mobile Web Viewer option
Ed events can be viewed online using STM Mobile web
viewer from MCDI. STM permits events viewing with
alarm code description on iPhone, Android phones or
iPad like devices with internet access.
STM is sold separately from Ed or D4. It is bundled with some Securithor versions
Turn your PC
into a powerful
alarm receiver
EXPRECIUM D
TM
makes alarm monitoring easy for Industries, Buildingx,
Health Services, College Campuses and Security departments.
EXPRE-
CIUM
TM
is MCDI’s 10th generation of PC based alarm receiver card. E
d
is
giving you the largest choice of alarm formats at affordable price. With
two phone lines per board, Exprecium gives you the power to turn your
PC into a powerful alarm receiver.
Exprecium fits into PCs with a PCI or PCI-E bus but can work indepen-
dantly from PC. Starting with one board, you can add boards as your
Monitoring Station grows. ARC of all sizes have trusted MCDI receiver
boards for more than 15 years.
Exprecium does not impose a logical limit to the number of cus-
tomers per line and comes with a 4095 events memory, Caller ID,
independant lines, handshake tuning for faster receiving and multi-
languages configuration tool. Works even if Windows OS is down.
RoHs compliant for China, Europe, Japan, Turkey.
model shown can differ from
production unit
