Specifications

pages 6 23
Especificaciones preliminares:las especificaciones pueden variar sin previo aviso. Por favor verifique nuestro sitio web para tener siempre la última información
operation. Internal temperature sensor alerts you of temperature warning
especially in close rack operation or when running in tropical climates.
Based on MCDI Security Products Generation 3 programming, all line
card have tuning possibilities to get a fast handshake with panels. Most
parameters configurable by front panel. All parameters configurable by
connected Windows computer over IP.
Remote upgrade and control
Upgrades and support are easily done by MCDI SP support staff over IP.
With small form factor, operation and signal redun-
dancy, D6 can be installed at remote location for
multi-city Monitoring. Configuration over IP using
SSL encryption.
Remote diagnostic
Integrated remote diagnostic function enables
MCDI SP to troubleshoot and upgrade D6 units
over IP when the unit is connected to the internet.
A special 2 way secure procedure lets you enable
this function only when you decide it and will only
allow MCDI SP support personnel who will trouble-
shoot, configure or upgrade your unit even from
the other side of the world.
MEMORY and logs
D5/D6 are equipped with the largest memory in
the industry: 8,000,000 events for 6 lines! Logs are
also available and stored on SD card located at the back of unit. SD card
can be substituted and increase for larger log keeping. Logs are available
for download over IP as comma delimited. Windows compiler supplied for
easy descriptive stats and analysis of traffic such as number of calls per
line and distribution in time.
Connectivity
D5/D6 output to CMS software using Serial output (flow control) or IP.
Multiple D6 can be connected to IP HUB/switch) connected to Server/PC of
CMS software such as SECURITHOR.
Connected Station Requirements
D5/D6 basic configuration can be achieved without PC from front display.
Configuration using integrated web server using Web browser Webkit
compliant.
IP audio: PC with SECURITHOR audio module.
IP reporting: Windows XP, VISTA or 7
USB: available to Windows 98, ME, 2000, XP, Linux 2.6+.
Serial output: DOS , Windows 9x, Me, 2000, XP, VISTA, Linux
Output only: DOS, Windows 3.1, WIN 9x and ME, Linux
Output and configuration: WIN XP, VISTA and 7(with .net 2.0 installed)
Dimensions
Standard one rack-mount unit 19 inches (W) x 1.75 in (H) x 10 in (L)
Aluminium, anodized finish. Weight: 2.5 Kg. Shipping weight 4.5 Kg.
Available as D5, D5r (without audio module) or D6 audio module available
Q4 2012.
Integrated listen-in/2 way audio
Each time D5 and D6 recognizes a listen-in or 2 way audio code such
as Contact ID E606, The phone line is kept open to allow communication
between operator and subscriber trough compatible alarm panel. This is
one of the least costly way to check for false alarms. In D6, Audio from
the phone line is routed on LAN over IP to the operators headset for bi-
directional audio communication. When used with MCDI’s specially pro-
grammed YATE SIP client this routing is made automatically insuring the
audio signals gets routed to the operator currently processing the alarm
signal. No high cost PBX or transfer system needed and a lot of space sav-
ing. Phone client ready for SECURITHOR ST1.2 and network versions. IP
phone client (Win XP, Vista and 7) supplied .
PERS at low cost.
Multiple destination reporting, 2 way voice/listen-in to IP audio make D6
the best package for any Central who wants to go into PERS Personal
Emergency System monitoring without encountering the costs of PBX and
transfer systems. D6 audio IP format is compatible with SECURITHOR from
MCDI and delivered with windows phone applications. Operators can link
to alarm lines and talk through headsets connected in their PC’s sound
cards. Compatible with Tunstall TTnew format.
Automation software Compatibility
D5/D6 are compatible with most Automation Software on the market in-
cluding SECURITHOR, SAMM, WINSAMM, Patriot, A-traq, Bold, SIS, SIMS,
Centralworks. Reporting to Automation software in MCDI, MCDI enhanced,
SG MLR2, MRL2000 modes. Support 3 digits line numbers and 3 digits
receiver numbers in MCDI and SG enhanced modes.
Receives most alarm protocol on the market from Pulse to SIA.
LCD display
D5/D6 provides on screen readout of alarms using standards Contact ID
and SIA tables.
Status of most important parameters available on front LCD at all time.
Heartbeat, lines status, dead line detection, power sources are all reported
on front graphic LCD. Buttons and LCD are backlighted for night/low light
