1.
Shelf Freezer Pocket loe Tray Ice Cube Box Door Gasket Sliding C: Egg Rack g Case Temperature Control Free Pocket (freezer compartment) Temperature Control (refrigerator compartment) Room Light Adjustable Pocks PCS) (MR-455CL 3 PCS) Glass Sharif PCS) Door Gasket (MR-455CL 4 PC8) Bottle Pocket Vegetable Case Cover Battle Stopper Drain Pan Vegetable Case Leveling Legs Toe Rile This illustration shows series models MR-385CL, MR-420CL, MR-455CL
L 2. Installation # Install on a completely flat and rigid surface. # Using the two front adjustable fest, ensure that the refrigerator is positions firmly and level on the orifice. Now ops the doors approximately half way, and extend the front adjustable feet equally until the doors close by themselves. Toe Grille Yt Leveling Leg + To ensure adequate ventilation for your refrigerator, spaces of 20mm on both sides, 50mm at the rear, and 100mm above the refrigerator are recommended.
L 3. Electrical Connections Important: For personal safety, this appliance must be properly grounded. « The refrigerator should always be plugged into its own individual electrical outset. This is recommended for best performance and also in order to prevent the overloading of household wiring consults, which may cause a fire hazard. Extension cords are not recommended. Marks sirs that the outset provides the comet voltage. o If your refrigerator has a grounding plug, use it comely.
L 4, Sliding Case o This sliding case Is cooled to a low temperature In order to preserve the freshness of foods stored for long periods. Lid & Open by pulling the case out. i CAUTION: Ba fore closing the refrigerator compartment door, make sure that the sliding case Is pushed all the way In (and the Ild Is closed correctly). o Remove the Iid and sliding case as shown In the illustration and proceed with cleaning. * Pull the case out.
L 7. Door Racks The door racks may be used to store all those little items that seem to get in the way. If you put all the small items in one place, you'll find that there’s more space inside the refrigerator for larger items. Free Pocket with Egg Tray ¢ Many eggs may be stored in the free pocket {Fig. 1). # If you tum half the egg tray over, small items may be stored together with the eggs (Fig. 2). * You can even tum the whole agg tray over and store small items in the free pocket instead of eggs (Fig.
L 5. Maintenance When performing maintenance, make absolutely sure that the power plug is first disconnected from the power outlet. # Dip a soft cloth into cold or lukewarm water, wring it out well and wipe. e If you do not clean the door gasket (especially the lower part} when it is dirty, the gasket will easily become damaged. Therefore, keep it clean at all times. « Do not clean with cleanser, acids, benzine, thinner, boiling water, soap powder, chemical cloths or neutral detergent.
L 6. Safety Advice The suggestions below apply to the operation of your home electric refrigerator. Mitsubishi Electric Corporation recommends these safety precautions. If your old refrigerator is sill in your house but not in use, ba sure to remove the door(s). This will ensure that children will not get frappes inside. Neva unplug your refrigerator by pulling on the cord. Airways take hold of the plug firmly and pull it straight out of the socket.
L ‘When the refrigerator is not cooling sufficiently The food may be packed too tightly together, which blocks the flow of cool air. You may have put hot or too many items into the refrigerator. The door may not have bun closed properly. The door gasket may be damaged. The refrigerator may not be well-ventilated. There may be insufficient clearance between the refrigerator and the surfaces immediately aside and above. The temperature control dial may not be properly set.
L 8. How to attach and insert vegetable case cover Attach Vegetable case cover with compartment shelf. Insert the Vegetable case cover into the rails of Refrigerator compartment shelf, after that slide up the Vegetable case cover and fit to the compartment sheaf. As shown in the picture. Insert the attached Vegetable case cover and compartment shelf into the rails (both left and right) upon the vegetable case. Then insert the vegetable case.
L MITSUBISHI ELECTRIC CORPORATION HEAD OFFICE : TOKYO BUILDING 2-7-3, MARASCHINO, CHIYODA-KU, TOKYO 100-8310, JAPAN PHONE: +81 (3) 3218-2111 MitsubishiElectric.com Distributed by: MITSUBISHI ELECTRIC AUSTRALIA PTY LTD. (Incorporated in New South Wales) ABN 58 001 215 792 New South Wales: 348 Victoria Road, Chalmers NSW 2116 Ph: (02) 9684 Fax: (02) 9898 0484 Queensland: Unit 12, 469 Nudge Road.
