Use and Care Guide

25300 AL MOEN DRIVE
•
NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: (800) 321- 8809 • FAX: [phone]
INTERNATIONAL: (440) 962- 2000 • FAX: [phone]
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: [phone]
WWW.CSI.MOEN.COM

Copyright Creative Specialties International 2006
Towel Bar
posts are constructed of
zinc. Bar is aluminum.
q
YB5424CH
–
24” Towel Bar
Chrome Finish
q YB5424WR – 24” Towel Bar
Wrought Iron Finish
q YB5424BN – 24” Towel Bar
Brushed Nickel Finish
q YB5424AN – 24” Towel Bar
Antique Nickel Finish
q YB5424ORB – 24” Towel Bar
Oil Rubbed Bronze Finish
q YB5424AZ – 24” Towel Bar
Antique Bronze
Cleaning Instructions:
Stock Number:
______________________
Double
Towel Bar
By Creative Specialties
Materials:
Stock Numbers:
Dimensions:
Double
Towel Bar
YB5422
Kingsley Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Literature #
BA1482
Directions below are for installation into drywall. If installing product into
a stud, use the wood screws only.
1. Remove mounting posts from the product assemblies by loosening
each setscrew.
2. Position the mounting template on the wall in the desired location
3. Using a level, align the template and tape it to the wall.
4. Drill two 5/16” holes at each mounting post location that corresponds
to your product.
5. We recommend using the horizontal holes for drywall installation.
6. Remove the template from the wall.
7. Fold ends of the plastic toggle anchor together and insert into each
hole in the wall.
8. Lightly tap anchors until flush with the wall.
9. One at a time, insert plastic pin into each anchor and lightly tap to
activate anchor.
10. Remove pin and repeat on all anchors.
11. One at a time, place each mounting post over anchors (notch facing
downward) and insert screws through post into anchors.
12. Tighten screws.
Installation Instructions:
