Specification Sheet

Paper Holder posts are constructed
of zinc. Roller is plastic.
 YB8000CH – Mounting Posts
Chrome Finish
 YB8099CH – Paper Roller
Chrome Finish
 YB8000OWB – Mounting Posts
Old World Bronze Finish
 YB8099OWB – Mounting Posts
Old World Bronze Finish
 YB8000PB – Mounting Posts
Polished Brass Finish
 YB8099PB – Paper Roller
Polished Brass Finish
 YB8000BC – Mounting Posts
Brushed Chrome Finish
 YB8099BC – Paper Roller
Brushed Chrome Finish
 YB8000SN – Mounting Posts
Satin Nickel Finish
 YB8099SN – Paper Roller
Satin Nickel Finish
Cleaning Instructions:
1. Position Pro-Fit Installation Mounting Template on wall in desired
location.
2. Using level align the template to the wall.
3. Using ¼” drill bit, drill one pilot hole for each post.
4. Position mounting post to wall by inserting wall anchor into pilot hole
and pressing firmly.
5. Make sure that locking tab on mounting post is facing down (6
o’clock).
6. Tighten wall anchor screw while holding mounting post firmly in
place.
7. Attach post by pressing firmly to mounting post until it clicks. (The
square opening at the base of the post must be facing down to
match-up with locking tab.)
8. Place spring roller into each post.
Stock Number:______________________Paper Holder
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Paper Holder
YB8099
Mason® Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
25300 AL MOEN D R I VE  N OR TH OLMSTED , OH 44070
C OR PORATE H EADQU AR TER S: (800) 321 -8809  F AX: [phone]
I N TERN ATION AL: [phone]  F AX: [phone]
C U STOMER SER VI C E (USA): 800-882-0116  F AX: [phone]
W W W . MOEN. C OM
Copyright Creative Specialties International Literature #BA1228
