User Guide,

Universal Serial Network

Manual # 42-02-S028, Rev A1, December 2008

Summary of content (20 pages)

PAGE 1
Motion Control Engineering, Inc. 11380 White Rock Road Rancho Cordova, CA 95742 voice 916 463 9200 fax 916 463 9201 www.mceinc.
PAGE 2
Copyright © 2008, Motion Control Engineering. All Rights Reserved. This document may not be reproduced, electronically or mechanically, in whole or in part, without written permission from Motion Control Engineering. Trademarks All trademarks or registered product names appearing in this document are the exclusive property of the respective owners.
PAGE 3
End User License Agreement This End User License Agreement (“Agreement”) grants you the right to use the software contained in this product (the “Software”) subject to the following restrictions: You may not: (i) copy the Software, except for archive purposes consistent with your standard archive procedures; (ii) transfer the Software to a third party apart from the entire product; (iii) modify, decompile, disassemble, reverse engineer or otherwise attempt to derive the source code of the Software; (iv) exp
PAGE 4
Important Precautions and Useful Information This preface contains information that will help you understand and safely maintain MCE equipment. We strongly recommend you review this preface and read this manual before installing, adjusting, or maintaining Motion Control Engineering equipment.
PAGE 5
Contents In This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 USN Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 IMC, PTC, PHC Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Mounting the Board Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 6
ii Manual # 42-02-S028, 12/30/08
PAGE 7
• • • • • • Installation Configuration Communication Connect MC USN Information Security Password IMC KCE Functionality MCE Universal Serial Network In This Manual This manual describes installing and setting up the MCE Universal Serial Network product. The USN is used to allow equipment without appropriate networking capabilities to communicate with state-of-the-art, MCE software applications including iMonitor, iReport, and BMS-Link.
PAGE 8
MCE Universal Serial Network USN Installation Installation instructions include: • MCE IMC and PTC/PHC Controls • Motion 3000ES Escalator Controls • USN Power Connection Note After mounting USN components in your equipment, ensure that no serial, ethernet, or CAN connections are made to the device. Only power should be connected during initial setup.
PAGE 9
USN Installation Mounting the Board Assemblies 1. Determine an appropriate location for the USN-BASE assembly. (Preferred location is in the upper left quadrant of the control enclosure.) 2. Mount the board, facing outward, such that access to critical controller components is not blocked. 3. For PTC/PHC programmable controllers, mount the M2C assembly near the USN-BASE assembly.
PAGE 10
MCE Universal Serial Network Configuration After connecting power, “INITIALIZING BOARD COMM” will appear on the USN-BASE assembly LCD display. Device Type Note It is important that all communication wires are disconnected from the USN board before changing the device type. Make sure all ethernet, CAN, and serial cables are disconnected.
PAGE 11
Configuration Escalator Only If you are not configuring an escalator, proceed to IP Setup. An escalator connection has additional parameters that need to be configured. Please note: each escalator must have its own unique lift number. 1. Place switch F7 in the up position. Using the keypad as described earlier, set and save: • Job Name: Defines the job name displayed on the iMonitor Summary screen. • Job Number: Defines the job number displayed on iMonitor Summary screen.
PAGE 12
MCE Universal Serial Network Communication Connections Connections are described for IMC, PTC/PHC, and Motion 3000ES. IMC 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly. 2. Connect the supplied C-RJ11/DB9M cable from a controller MC-RS (serial board) COM port to RS232 Port B (J7) on the USN-BASE assembly. 3. Through the controller MPU board, set the connected COM port to media= serial and device= PC. 4. On the MC-RS board, set the connected COM port slide switch to DCE.
PAGE 13
Communication Connections PTC/PHC 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly. 2. The boards in the controller are connected along a ribbon cable bus. Connect the M2C assembly’s “From PCA” (JP3) to the last controller board on the bus using supplied ribbon cable. The last board on the ribbon cable bus will have an empty socket. Make the connection from this socket. 3.
PAGE 14
MCE Universal Serial Network Motion 3000ES 1. Connect the CAN bus wires from the three-wire terminal on lower right side of the HCMPU (USN) board labeled “External Network” to escalator EC-MCB board, J12. • Connect CAN H to J12 TB. • Connect CAN L to J12 TA. • The SHLD is only connected on the HC-MPU (USN) side. 2. Press RSTA to reset the USN board so that it will read its new connections.
PAGE 15
MC USN Information MC USN Information This section describes the features of the USN device. Jumper Settings These jumper settings apply to the Rev X3-0 version of the MPU-M board.
PAGE 16
MCE Universal Serial Network LCD and Keypad • Trim pot R27 adjusts LCD screen contrast. • The interface uses eight functional switches and 4 buttons. Operating Displays Upon initial power-up, the board should display the following message: If the display never changes from this message, verify that the SW1 switch is in the down (ETHERNET PORT A) position.
PAGE 17
MC USN Information Once the USN has connected to the device it will display the following message: This indicates that the USN board has successfully established connectivity with the device. If the following message is displayed: The USN board is not receiving data from the device. Troubleshooting • Recheck you connections to the board. Ensure that all proper connections have been made based on the device type.
PAGE 18
MCE Universal Serial Network • Translation Loop Progress: This screen displays the progress of translating events, parameters, and monitors from the device protocol to the client protocol. MCE use only. • Internal Address Data Values: This option is used to dial USN memory addresses and view their contents. The functional switches and buttons are used in this mode to change the format of the information displayed.
PAGE 19
Security Password Default for IMC Connections Security Password Default for IMC Connections If the USN is connected to an IMC controller with the CRT Security feature enabled, the USN will allow iMonitor software to configure security parameters. In order to configure security parameters, a user must log into the controller using a password. This password is stored on the USN board. The default password is “manager”. If it is lost, the password can be reset back to default: 1.
PAGE 20
MCE Universal Serial Network 14 Manual # 42-02-S028 A1
