When browsing Groups, you can choose to load each Group with or without its Patterns. This is
done by clicking the Load Patterns button at the bottom of the Browser:
The Load Patterns button.
▪ Load Patterns button enabled: Groups will be loaded together with their Patterns. This al-
lows you to use the Patterns you have saved with the Groups. Upon loading, all Patterns
of the focused Group will be replaced, and a Clip referencing the first Pattern will be cre-
ated in the selected Scene.
▪ Load Patterns button disabled: Groups will be loaded without their Patterns. This allows
you to load another set of Sounds while keeping your current Patterns. Notably, this can
be very useful to try another drum kit with your current Patterns!
The Load Patterns checkbox is available only when browsing Groups.
3.3.3.1 Loading Groups with their Patterns on the MASCHINE STUDIO Controller
When browsing Groups on your controller:
►
Press Button 7 (+ PATTERNS) to include or exclude Patterns when Groups are loaded.
→
When the option is enabled (Button 7 lit and + PATTERNS label highlighted), Groups are
loaded together with their Patterns.
3.3.4 Displaying File Information
The Information button.
►
Click the Information button (showing a little “i”) next to the EDIT button in the right
part of the Control bar to display information on the file(s) selected in the Result list.
→
A box appears above with various information on the selected file(s): File Format, Date
modified, File Size, Type, as well as the Author and Vendor properties, if any (see section
↑3.4, Editing the Files’ Tags and Properties).
