would now have to try to remember the name or the tags you used to find it, or browse all kick
Samples (given that the MASCHINE Library already has several hundreds of kick Samples, this
may take a considerable amount of time). With Quick Browse you can restore the query with
just one click.
Quick Browse is available for Samples, Plug-ins presets (Instruments and Effects), Sounds,
Groups. Depending on the type of file you are looking for, the Quick Browse function is activa-
ted by clicking the magnifying glass in either of the following locations:
▪ Quick Browse for Projects, Groups and Sounds: Click the magnifying glass right of the col-
ored file name appearing in the upper left part of the Control area to recall the search
query that was used for that file. That file will be:
◦ The focused Group if the GROUP tab is selected above:
◦ The focused Sound if the SOUND tab is selected above:
▪ Quick Browse for Instrument/Effect presets and for Samples: Click the magnifying glass in the
upper right corner of the Control area to recall the search query that was used for the
Plug-in in the selected slot:
Browser
Using Quick Browse
MASCHINE STUDIO - Manual - 130
