on these parameters. But you can select additional objects on top of the focused object,
thereby extending your selection. Selected objects are highlighted in the Sound/Group
List but their leading letter and/or number stays gray.
Other Sounds were added to the selection (but they are not focused).
More precisely, if a Group or a Sound is currently focused, you can additionally select other
Groups or Sounds, respectively. These will be also affected by your edits on the focused Group
or Sound.
You cannot select Sounds and Groups simultaneously.
Each Group remembers its own Sound selection and focus.
When setting the focus to a new Sound or Group, following rules apply:
▪ If you set the focus to a Sound or Group which is not selected, both the focus and the
selection are moved to this new Sound or Group.
▪ If you set the focus to a Sound or Group which is already included in the current selec-
tion, the focus is moved to this new Sound or Group but the selection is preserved. This
notably allows you to check the parameters of any selected Sound or Group while keeping
the ability to modify parameters for the entire selection.
What Is Affected by the Multiple Selection, and How?
When multiple Sounds or multiple Groups are selected, any change in the following settings of
the focused Sound/Group will be mirrored in the other selected Sounds/Groups, respectively:
Managing Sounds, Groups, and Your Project
Overview of the Sounds, Groups, and Master
MASCHINE STUDIO - Manual - 139
