You can also recall the search query that was used to find the Sound currently loaded in
the focused Sound slot. See section ↑3.7, Using Quick Browse for more information.
In your operating system, Sound files have the extension “.mxsnd” (MASCHINE 2) or
“.msnd” (MASCHINE 1.x).
Please refer to chapter ↑3, Browser for more information on the Browser.
4.2.1.1 Loading Sounds on Your Controller
On your controller, use the Browser to load Sounds:
▪ You can browse your MASCHINE Library for the desired Sound. For more information on
how to do this, please refer to section ↑3.2, Searching and Loading Files from the Library.
▪ Alternatively you can recall the search query that was used to find the Sound currently
loaded in the focused Sound slot. See section ↑3.7, Using Quick Browse for more infor-
mation.
4.2.2 Pre-listening to Sounds
You can pre-listen to the Sounds of the focused Group as you set the focus on them in the
software. To do this:
►
Click the speaker button above the Sound List (or the Pad view) to enable/disable Sound
pre-listening in the focused Group:
→
When the speaker button is enabled, each time you set the focus on a Sound by clicking
it in the Sound List or in Pad view, this Sound will be played back. This is useful as
quick reminder of the various Sounds loaded in the Group.
Managing Sounds, Groups, and Your Project
Managing Sounds
MASCHINE STUDIO - Manual - 145
