2. While holding the mouse button, drag your mouse vertically toward the desired location in
the Group List.
As the mouse cursor moves, an insertion line appears at the potential places where you
can drop the Group.
3. When the insertion line appears at the desired location, release the mouse button.
→
The Group takes its new place in the Group List. Of course, this new place is also mir-
rored on your controller.
4.3.8 Deleting Groups
Deleting a Group will remove it from the Group List.
You can select multiple Groups to delete them all at once! See ↑4.1.3, Selecting Multiple
Sounds or Groups for more information.
►
To delete a Group, select it in the Group List and press [Del] on your computer keyboard.
You can also right-click (on Mac OS X: [Ctrl]-click) the Group in the Group List or the
Group name in the top left corner of the Pattern Editor and choose Delete from the con-
text menu.
→
The Group is removed. All following Group are shifted up in the Group List to fill the gap.
If the last Group bank is empty after the Groups have been shifted, the bank is deleted.
Managing Sounds, Groups, and Your Project
Managing Groups
MASCHINE STUDIO - Manual - 165
