Element Description
Source
Output menu and Out-
put list underneath
Selects what will be exported. The content of the Output list under the menu de-
pends on your selection in the menu:
Master Output: Select this to export the Master output signal (including all Groups
and Sounds and their effects) to one audio file. The Output list underneath contains
only one entry: Master Output. This entry is checked and grayed out (you cannot un-
check it).
Group Outputs: Select this to export the output signals of specific Groups to individ-
ual audio files. The Output list underneath shows all Groups available for exporting.
Empty Groups (i.e. Groups containing only empty Sound slots) are not listed. Click
the check boxes of the desired entries in the list to include/exclude the correspond-
ing Groups. Only Groups with a check mark will be exported.
Sound Outputs: Select this to export the output signals of specific Sounds to indi-
vidual audio files. When this entry is selected, the Output list underneath shows all
Sounds available for exporting. Empty Sound slots are not listed. The entries are or-
ganized as a tree with Groups at the root and Sounds within each Group. By default
all Groups are collapsed and all Groups and Sounds are checked. Click the little ar-
row left of a Group to show/hide its Sounds. Click the check boxes of the desired
entries in the list to include/exclude the corresponding Sounds. Only Sounds with a
check mark will be exported. The check box of Group entries allow to check/uncheck
all Sounds of the Group at once. If some of the Sounds only are checked in a Group,
the Group is “dimmed checked.”
Destination
Folder Displays the folder on your hard disk where the exported audio file(s) will be saved.
To change the destination folder, click the field and select the desired folder in the
navigation dialog that opens.
Export Audio Panel – Options Page
The Options page of the Export Audio panel allows you to adjust various settings for the export
process.
Managing Sounds, Groups, and Your Project
Exporting MASCHINE Objects and Audio
MASCHINE STUDIO - Manual - 172
