▪ If Sound Outputs is selected in the Output menu the audio files will be named as follows:
[Project name] - [Sound name] - [BPM].wav
In addition, if the name of the file about to be exported is already used in the destination
folder, a hyphen followed by an index number is added to the name (e.g., “ - 1,” “ - 2,” “ -
3,”) to avoid any file being overwritten.
4.5 Importing Third-Party File Formats
4.5.1 Loading REX Files into Sound Slots
MASCHINE supports REX (ReCycle) files to be loaded. REX files are loops that are already
sliced and mapped to MIDI notes.
Only REX2 files are currently supported.
→
The Samples are loaded into the Sound slot. A new Pattern is created in that Group and
directly loaded in the Pattern Editor (switch the Pattern Editor to Keyboard view to better
see the Pattern — see section ↑7.1.5, Group View and Keyboard View). This Pattern con-
tains the sequence data of the REX file. For each REX file you import a Pattern will be
created and added.
A REX file loaded in the first Sound slot.
Managing Sounds, Groups, and Your Project
Importing Third-Party File Formats
MASCHINE STUDIO - Manual - 175
