4.5.2 Importing MPC Programs to Groups
MASCHINE allows you to import Drum program files (.PGM and .AKP) from the Akai MPC ser-
ies to Groups. Supported models include the MPC4000, MPC3000, MPC2000, MPC500,
MPC1000 and the MPC2500.
Supported Parameters from MPC Programs
Since MASCHINE has a different approach to handling and naming parameters, please refer to
this list to find out how MPC Program settings are being translated into MASCHINE settings.
MPC Parameter MPC500,
1000, 2500
MPC4000 MPC2000
(XL)
MPC3000 MASCHINE Parameter
Sample Name x x x x Sample Name
Play Mode x x − − Playback Type (ADSR,
One-shot, AHD)
Sample Level x x − − Zone Level
Sample Pan − x − − Zone Pan
Range Lower/Higher x x − − High/Low Key
Tuning x x x x Tune
Attack x x x x Attack
Decay x x x x Decay
Voice Overlap x − x x Polyphony
Filter1 Type x − − − Filter Type
Filter1 Frequency x − x x Filter Cutoff
Filter1 Resonance x − x x Filter Resonance
Filter1 Velocity to Fre-
quency
x − − − Velocity Cutoff
Mixer Level x x x x Track Level
Mixer Pan x − x x Track Pan
Managing Sounds, Groups, and Your Project
Importing Third-Party File Formats
MASCHINE STUDIO - Manual - 176
