If you hit the pads now, you will hear that they all play the same Sound, but each with a
different pitch. When you leave Pad Mode, the PAD MODE button stays dim lit to indi-
cate that Keyboard mode is active.
Alternatively, you can use the following shortcut:
►
In any mode, press SHIFT + PAD MODE to quickly switch your pads between Keyboard
mode and Group mode.
The pitch scale is divided in semitones, starting with pad 1 as the lowest pitch going up to pad
16 as the highest pitch. The current scale is indicated on the right display:
Keyboard mode selected on the controller displays in Pad Mode.
Activating Keyboard mode on your controller automatically switches the Pattern Editor to
Keyboard view in the software, and inversely.
To shift the scale in octaves use Button 5 (octave down) or Button 6 (octave up). You can also
shift the scale in semitones: use Button 7 (semitone down) and Button 8 (semitone up). Of
course all these settings stay active when you press PAD MODE again to leave Pad Mode.
Try to experiment with all kinds of Samples in the Keyboard mode; some rather boring
sounding Samples can be really interesting if you play them very low or very high!
If you prefer to play your melodies with a MIDI keyboard, you can connect one to the MIDI IN
socket on the back of your controller. You can also use any USB-MIDI keyboard selected in the
Audio and MIDI Settings panel (see section ↑2.6.2, Audio and MIDI Settings – Routing Page
to get to know how to set these up). By default the connected MIDI input device will always
play the selected Sound without the need to enter Keyboard mode.
Playing on Your Controller
Adjusting Your Pads
MASCHINE STUDIO - Manual - 183
