The rear side of the MASCHINE hardware with the MIDI IN and OUT sockets.

5.1.3 Adjusting the Base Key

In Group mode, the base key defines the key (or pitch) at which the selected Sound will be

played when its pad is pressed. In Keyboard mode, it defines the key played by pad 1 on your

controller; pads 2–16 will then play keys from [base key + 1 semitone] up to [base key + 15

semitones].

The base key also affects the pitch of events created via the step sequencer. See section

↑7.3.1, Step Mode Basics for more information on this.

Adjusting the base key only affects the notes played by the pads of your controller. It does

not affect the notes recorded in your Patterns! To adjust the key of notes in Patterns,

please refer to section ↑7.4, Editing Events.

You can select multiple pads and quickly change the base key for all of them at once! See

section ↑4.1.3, Selecting Multiple Sounds or Groups to know how to do this.

By default the base key of every Sound slot is C3 (i.e. middle C in the MASCHINE convention).

To change the base key of the selected pad(s) / Sound slot(s) in the software:

1. Click the Pad View button above the Sound List in the Pattern Editor to show the Pad

view for the focused Group.

2. Click the Key value and drag your mouse vertically, or double-click it, enter a new value

on your computer keyboard, and press [Enter] to confirm.

5.1.3.1 Adjusting the Base Key on Your Controller

To change the base key of the selected pad(s) / Sound slot(s) on your controller:

Playing on Your Controller

Adjusting Your Pads

MASCHINE STUDIO - Manual - 184
