5.2.1.1 Using Note Repeat on the MASCHINE STUDIO Controller
Note Repeat is a hardware-only feature.
►
Press and hold NOTE REPEAT to enter Note Repeat mode. You can also press NOTE RE-
PEAT + Button 1 to pin this mode and make it permanent.
The Note Repeat mode on the controller.
In Note Repeat mode you can customize the way your Sounds/notes will be repeated by adjust-
ing following settings:
Element Description
Button 5–8 Select between four different presets — also while playing. The rate currently as-
signed to each button is indicated below on the display. The selected rate is
highlighted. You can change the rate and rhythm assigned to each button by se-
lecting it and using Knob 2 and 3, respectively (see below).
RATE (Knob 2) Adjusts the rate assigned to the selected Button 5–8. Available values are 1 BAR
and a series of note values going from 1/2 (half note) until 1/128 (a hundred twen-
ty-eighth note).
TYPE (Knob 3) Selects from three variations of the original note length defined by the RATE pa-
rameter: NORMAL plays the original note length (default setting), TRIPLET plays trip-
lets of the original note length (faster, three notes in the duration of two original
notes), and DOTTED plays dotted versions of the original note length (slower, two
notes in the duration of three original notes). Under Button 5–8, triplet values
are indicated by a “T” and dotted values by a “D” next to the note value.
