put properties (see section ↑8.1.2, Configuring the Main Output of Sounds and Groups) as well
as in Solo and Mute mode on your controller: Activating the audio mute for Sounds will ensure
that not only the events are muted, but any remaining audio as well.
To momentarily mute all audio from all Sounds and Groups at once, please refer to section
↑5.2.3, Choke All Notes.
Soloing a Sound
►
To solo a Sound, right-click (on Mac OS X: [Ctrl]-click) the number on the left side of the
Sound slot in the Pattern Editor.
Soloing the first kick Sound.
►
To unsolo a Sound, right-click (on Mac OS X: [Ctrl]-click) the number again.
Soloing a Group
►
To solo a Group, right-click (on Mac OS X: [Ctrl]-click) the Group index (letter + number)
on the left side of the Group in the Arranger:
Soloing a Group.
Playing on Your Controller
Playing Tools
MASCHINE STUDIO - Manual - 191
