The Mute mode on the controller.

1. Press and hold MUTE to enter Mute mode. You can also press MUTE + Button 1 to pin

this mode and make it permanent.

2. Mute Sounds by pressing their pads, and mute Groups of the current Group bank by

pressing their Group buttons. Press Button 3 and 4 to switch to the previous/next Group

bank, respectively.

In both Solo and Mute modes you will note the following:

▪ On your controller, the unmuted pads and Group buttons are fully lit, while the muted

ones are dim lit (and the empty ones are off).

▪ On the displays, the unmuted Sounds and Groups are highlighted while the muted ones

are not (and the empty ones are… empty).

In both modes the displays provide a few more functions:

▪

ALL ON (Button 5) turns all Sounds on in the selected Group.

▪ NONE (Button 6) turns all Sounds off in the selected Group.

▪ When holding Button 8 (AUDIO) you can see on the pads which Sounds have audio mute

enabled (see above): Sounds with audio mute enabled have fully lit pads, while Sounds

with only event mute have dim lit pads. This is also indicated on the right display (Sounds

with audio mute are highlighted). While holding Button 8 (AUDIO), press any pad to switch

the audio mute for this Sound on or off.

Enabling/disabling audio mute for a Sound does not mute/unmute it! It only sets this

Sound to get both its events and its audio muted when you will mute it via the usual way

(pressing MUTE + its pad).

Playing on Your Controller

Playing Tools

MASCHINE STUDIO - Manual - 194
