Level Shortcuts in the Master Section
The Master section of your controller allows you to quickly adjust various level values in your
Project.
The Master section of your controller, here with the GRP button active.
1. To change the output level of the Master (i.e. the overall output level of MASCHINE),
press MST and turn the Level knob.
2. To change the output level of the Cue bus, press CUE and turn the Level knob.
3. To change the output level of a Group, press its Group button (first navigate to its Group
bank if necessary), press GRP in the Master section, and turn the Level knob.
4. To change the output level of an individual Sound, press its pad (or press SELECT + its
pad if pads are in Keyboard mode), press SND in the Master section, and turn the Level
knob.
→
The adjusted value shortly appears on the left display. The level meter in the Master sec-
tion always displays the level corresponding to the selected button on the right.
Hold SHIFT while turning the Master encoder to adjust the value in finer increments.
