These shortcuts control the LEVEL parameter of the Audio and Cue section in the Audio page of
the Master’s Output properties as well as the LEVEL parameter of the Audio section in the
Audio page of the Group’s and Sound’s Output properties, respectively. See section ↑8.1.4,
Configuring the Master and Cue Outputs of MASCHINE and ↑8.1.2, Configuring the Main
Output of Sounds and Groups for a detailed description of these properties.
In the software you can also adjust the output level of the Master via the Master Volume slider
in the right part of the Header:
The Master Volume slider in the software’s Header.
To reset the output level of the Master to 0 dB, double-click the Master Volume slider.
Level, Tune, and Groove Shortcuts via the Quick Edit functions
In the EDIT section of your controller you can use Quick Edit functions to quickly adjust the out-
put level, the tune, and the groove of your individual Groups and Sounds.
The EDIT section of your controller, here with the TUNE function active.
Playing on Your Controller
Playing Tools
