In the Plug-in List, the processing order is always from top to bottom.
In addition to Plug-ins, each Sound, each Group, and the Master also provide a set of glob-
al settings called Channel properties. These are described in section ↑5.2.4, Groove and in
chapter ↑8, Audio Routing, Remote Control, and Macro Controls.
Different Types of Plug-ins
Plug-ins can be of different types:
Instrument Plug-ins Effect Plug-ins
Internal Plug-ins Sampler, Drumsynths MASCHINE internal effects
Native Instruments Plug-
ins
VST/AU instrument plug-ins from Native
Instruments’ range of products
VST/AU effect plug-ins from Native In-
struments’ range of products
External Plug-ins Third-party VST/AU instrument plug-ins Third-party VST/AU effect plug-ins
▪ Instruments: These Plug-ins generate sound. Instrument Plug-ins can only be loaded in the
first Plug-in slot of Sounds. Following Plug-ins are available:
◦ Sampler: Included with MASCHINE, the Sampler Plug-in allows the selected Sound to
play back Samples. This is the most common sound source, as adding a Sample to
the Sound slot will automatically load the Sampler in the first Plug-in slot of the
Sound. See ↑6.2, The Sampler Plug-in for more details.
◦ Drumsynths: Included with MASCHINE, these Plug-ins are mini-synths specialized in
generating drum sounds. See chapter ↑10, Using the Drumsynths for more details.
◦ Native Instruments: You can use all Native Instruments KOMPLETE instruments instal-
led on your computer as VST/AU plug-ins (e.g., MASSIVE, which is included with MA-
SCHINE). Products from Native Instruments are tightly integrated in MASCHINE.
◦ External: You can also use VST/AU instrument plug-ins from any third-party manufac-
turers.
