You can also sample directly to a Sound slot. This will automatically load a Sampler in its
first Plug-in slot. Read chapter ↑12, Effect Reference for more details on this.
6.1.3 Loading, Removing, and Replacing a Plug-in
The procedure to load a Plug-in with its default settings is common to all levels (Sound, Group,
and Master) and all Plug-in types (Internal, Native Instruments, and External, as well as Instru-
ment and Effect):
1. Set the focus to the Sound, Group or the Master where you want to load the Plug-in (see
section ↑2.3.1, Setting the Focus on a Group or a Sound). In the picture below we click
an empty Sound slot in the Sound List of the Pattern Editor and click the SOUND tab in
the Control area above.
The Control area will now show the content (Channel properties or Plug-ins) of the Sound
we have just selected.
2. At the far left of the Control area, click the little plug icon to display the Plug-ins.
This displays the Plug-in List on the left of the Control area:
Working with Plug-ins
Plug-in Overview
MASCHINE STUDIO - Manual - 207
