The Plug-in is unloaded from the slot. All following Plug-ins are shifted one slot upwards

to fill the gap.

Furthermore, the Plug-in menu also allows you to replace the loaded Plug-in with another one:

►

To replace the Plug-in currently loaded in a slot, open its Plug-in menu and select anoth-

er Plug-in in the menu.

→

The original Plug-in is replaced with the newly selected one. The rest of the Plug-in List

stays untouched.

You can also recall the search query that was used to find the Plug-in preset currently loa-

ded in the Plug-in slot (see section ↑3.7, Using Quick Browse for more information).

Content of the Plug-in Menu

The entries in the Plug-in menu differ according to the Plug-in slot from which you are calling

the menu:

▪ The first Plug-in slots of Sounds accepts both Instrument and Effect Plug-ins. The entries

available in their Plug-in menu are listed in the following table.

▪ All other Plug-in slots at the Sound, Group, and Master level only accept Effect Plug-ins.

Therefore, their Plug-in menus and submenus provide the same entries except all entries

for Instrument Plug-ins.

The Plug-in menus can have following entries, from top to bottom:

Plug-in Menu Entry Description

Plug-ins

Presets submenu (only when a

Native Instruments or External

Plug-in is loaded)

Lists all VST/AU presets made available to MASCHINE by the VST/AU plug-

in. This allows you to use your favorite presets of the VST/AU plug-in direct-

ly inside MASCHINE. See section ↑6.3.4, Using VST/AU Plug-in Presets for

more information.

None Select None to remove the Plug-in currently loaded (see previous para-

graph).

Working with Plug-ins

Plug-in Overview

MASCHINE STUDIO - Manual - 210
