To bypass a Plug-in, do the following:
1. If you want to bypass a Plug-in of the Master, click the MASTER tab in the top left corner
of the Control area.
2. If you want to bypass a Plug-in of a Group, click the desired Group on the left of the Ar-
ranger, and click the GROUP tab in the top left corner of the Control area.
3. If you want to bypass a Plug-in of a Sound, click the Group of its parent Group in the Ar-
ranger, click the desired Sound slot on the left of the Pattern Editor, and click the
SOUND tab in the top left corner of the Control area.
4. In the Plug-in List, click the icon left to the Plug-in name (keys for an Instrument Plug-in,
FX for an Effect Plug-in) to bypass this Plug-in.
The Plug-in does not affect the sound anymore. The icon is grayed out to indicate that
this slot is now bypassed.
Use the same method to unmute the Plug-in:
►
To activate the bypassed slot again, click its grayed out icon.
In most cases the first Plug-in slot contains an Instrument Plug-in (e.g., a Sampler). Be
careful: bypassing the slot will mute the whole Sound!
6.1.5.1 Bypassing a Plug-in Slot on the MASCHINE STUDIO Controller
1. Press the PLUG-IN button to enter Control mode and display Plug-in slots.
2. If you want to bypass a Plug-in of the Master, press Button 1 to select the MASTER tab.
3. If you want to bypass a Plug-in of a Group, press Button 2 to select the GROUP tab and
press the Group button A–H corresponding to the desired Group. If necessary, first press
SHIFT + the desired Group button A–H to switch to the Group bank containing that
Group.
Working with Plug-ins
Plug-in Overview
MASCHINE STUDIO - Manual - 215
