Recalling Plug-in Presets
All Plug-in presets you saved as described above are available in the Browser, both in the soft-
ware and from your controller! You will find each Plug-in preset automatically placed in the
corresponding “Instrument” or “Effect” category in the File Type selector of the Browser’s LI-
BRARY pane. Furthermore, user presets will be available when selecting the User content in
the Content selector of the Browser’s LIBRARY pane.
For more information on how to load Plug-in presets in the Browser, please refer to chapter ↑3,
Browser.
You can assign tags to the Plug-in presets that you saved. This is done in the Browser in
the MASCHINE software. For more information, please refer to section ↑3.4, Editing the
Files’ Tags and Properties.
In addition, the MASCHINE library already provides a collection of Plug-in presets for MA-
SCHINE Internal Plug-ins. Furthermore, any Native Instruments product installed on your com-
puter will have its own factory library already imported into the MASCHINE Browser so that you
can browse and load its presets directly from MASCHINE, ready for loading.
KOMPLETE products and MASCHINE EXPANSIONS have to be updated to ensure their full
integration into the MASCHINE Library. To update any Native Instruments product instal-
led on your computer, please start the Service Center.
You can also load a Plug-in preset from the Plug-in menu by selecting the Open… command,
then navigating your file system and selecting the desired preset file (extension “.mxinst” for
Instrument Plug-in presets, “.mxfx” for Effect Plug-in presets, or “.mfxp” for MASCHINE 1.x
Module presets).
6.2 The Sampler Plug-in
The Sampler Plug-in allows you to play back any Sample in MASCHINE — including all
Groups, Sounds and Samples of the factory library. The Sampler comes with an extensive set
of parameters that offer various ways to further shape each of your Sounds individually. You
can tune, change basic dynamics and apply effects as well as different modulation options.
Working with Plug-ins
The Sampler Plug-in
MASCHINE STUDIO - Manual - 220
