Parameter Description
Pitchbend Here you can adjust how the Sound reacts on incoming MIDI Pitchbend messag-
es from an external MIDI controller or your host application. For more informa-
tion on how to setup your Sounds to receive MIDI, refer to section ↑8.2.1, Trig-
gering Sounds via MIDI Notes.
ENGINE
Mode This allows you to select between different models for the sampling engine. Be-
sides the default Standard setting, the other options MP60 and S1200 emulate
the sound of two legendary Samplers that are often used in Hip-Hop and similar
genres of music. The latter comes in various flavors offering different filtering:
S1200 (no filtering), S1200 L (for Low, i.e. low-pass filtering), S1200 LM (for
Low-Mid, i.e. low-mid-pass filtering), S1200 HM (for High-Mid, i.e. mid-high-
pass filtering), and S1200 High (for High, i.e. high-pass filtering).
6.2.2 Page 2: Pitch / Envelope
Sampler parameters – page 2 of 6: PITCH / GATE and AMPLITUDE ENVELOPE on the controller.
Sampler parameters – page 2 of 6: PITCH / GATE and AMPLITUDE ENVELOPE on the controller.
Sampler parameters – page 2 of 6: PITCH / GATE and AMPLITUDE ENVELOPE in the software.
Working with Plug-ins
The Sampler Plug-in
MASCHINE STUDIO - Manual - 223
