Parameter Description
Sustain (ADSR only) Sustain determines the constant level being kept after Decay until the note
ends. This can also be controlled by an external MIDI controller or keyboard us-
ing the MIDI Control Change 64.
Release (ADSR only) Release determines how long the sound takes to fade out after the note has
ended.
6.2.3 Page 3: FX / Filter
Sampler parameters – page 3 of 6: FX and FILTER on the controller.
Sampler parameters – page 3 of 6: FX and FILTER in the software.
FX
This is a small selection of basic effects, not to be mixed up with the collection of Effect Plug-
ins covered in depth in chapter 12.
Working with Plug-ins
The Sampler Plug-in
MASCHINE STUDIO - Manual - 226
