6.2.4 Page 4: Modulation
Sampler parameters – page 4 of 6: MODULATION ENVELOPE and DESTINATION on the controller.
Sampler parameters – page 4 of 6: MODULATION ENVELOPE and DESTINATION on the controller.
Sampler parameters – page 4 of 6: MODULATION ENVELOPE and DESTINATION in the software.
MODULATION ENVELOPE
The MODULATION ENVELOPE section offers an additional envelope allowing further modifica-
tion (or “modulation”) of specific Sampler parameters according to the way you play on the
pads. Its parameters are matched to those of the AMPLITUDE ENVELOPE section on page 2
(see ↑6.2.1, Page 1: Voice Settings / Engine), so that you have either an ADSR (Attack, Decay,
Sustain, Release) envelope or an AHD (Attack, Hold, Decay) envelope to modulate your param-
eters. If you choose One-shot mode, only the AHD envelope (pictured) will be available for
modulation.
Envelope Controls Description
Attack The time it takes for the envelope to reach its maximum level.
Hold How long the envelope will stay at its maximum level.
