7.2.3.1 Using the Metronome on the MASCHINE STUDIO Controller
On your controller:
►
Press METRO in the TRANSPORT section to activate or deactivate the metronome.
Adjusting the Metronome’s Volume and Time Signature
On your controller you can adjust the volume and time signature of the metronome in the re-
cording settings:
1. Press SHIFT + GRID to show the recording settings.
2.
Turn Knob 1 (Metronome LEVEL) to adjust the metronome volume.
3.
Turn Knob 2 (Metronome TIME) to select a time signature.
While adjusting the metronome settings you can enable/disable the metronome via But-
ton 2 (METRO). This is strictly equivalent to pressing METRO as mentioned above.
7.2.4 Recording with Count-in
Count-in allows you to start the metronome before the sequencer and recording begins. This is
very handy if you want to start recording a Pattern exactly on the downbeat.
When start recording with a Count-in, the following happens:
▪ The playhead jumps to the beginning of the Loop Range.
▪ You hear the metronome alone during the count-in phase (1, 2 or 4 bars).
