Editing Tool Description
Knob 1 (POSITION)
Nudges selected events, i.e. shifts selected events on the timeline according to
the Nudge Grid (the events’ offsets relative to the Nudge Grid are preserved). Hold
SHIFT while you turn the knob to temporarily override the Nudge Grid quantization
and adjust the positions in extremely small increments. See section ↑7.1.7, Ad-
justing the Step Grid and the Nudge Grid for more information on the Nudge Grid.
If one event only is selected, its position is shown under POSITION. If several events
are selected, the field shows (MULTI).
Knob 2 (LENGTH)
Moves the end of the selected events according to the Step Grid (the offset of
each events' end relative to the Step Grid is preserved). Hold SHIFT while you turn
the knob to temporarily override the Step Grid quantization and adjust the lengths
in extremely small increments. If the events have different lengths, the length dif-
ferences are retained as long as no event becomes shorter than one step.
When only one event is selected, its length is shown under LENGTH. If several
events are selected, the field shows (MULTI).
Knob 3 (PITCH)
Transposes the selected events by semitones.
When only one event is selected, its pitch is shown under PITCH. If several events
are selected, the field shows (MULTI).
Knob 4 (VELOCITY)
Adjusts the velocity of the selected events. If the events have different velocities,
the velocities differences are retained as long as the limits (0 and 127) are not
reached. When only one event is selected, its velocity is shown under VELOCITY. If
several events are selected, the field shows (MULTI).
These parameters are the same as in Event Edit mode. See section ↑7.4.4, Editing Selec-
ted Events/Notes for more information.
Quick Edit Shortcuts for the Selected Steps
You can also quickly adjust the velocity, pitch, and position of any events via the Quick Edit
shortcuts:
