Use the jog wheel and the FUNCTION buttons underneath for the Quick Edit shortcuts.
1. Press and hold the pad(s) of the step(s) you want to edit.
2. To adjust the events’ velocity, press the FUNCTION buttons until the VOLUME indicator
lights up under the jog wheel, and turn the jog wheel.
The adjusted value appears on the left display.
3. To adjust the events’ pitch, press the FUNCTION buttons until the TUNE indicator lights
up under the jog wheel, and turn the jog wheel.
The adjusted value appears on the left display.
4. To finely adjust the events’ position, press the FUNCTION buttons until the SWING indi-
cator lights up under the jog wheel, and turn the jog wheel.
The adjusted value appears on the left display.
5. When you are done, release the pad(s).
The event position will be adjusted independently of the current Step Grid: It is designed
as a fine adjustment within the current step.
Working with Patterns
Recording Patterns with the Step Sequencer
MASCHINE STUDIO - Manual - 282
