7.4 Editing Events
Many creation and editing commands on events/notes are available directly via mouse actions
in the Event area of the Pattern Editor. They will be applied according to the selected Step
Grid resolution (see ↑7.1.7, Adjusting the Step Grid and the Nudge Grid). In Group view, the
Sound in focus will change according to the row you click in. Selected notes are highlighted.
Events vs. Notes
Basically events and notes are the same thing: a trigger for a Sound with a particular velocity,
pitch, length, etc. If the word “note” is used when dealing with melodic instruments and
“event” when dealing with drum kits, keep in mind that both words have the same meaning in
the MASCHINE context.
7.4.1 Editing Events with the Mouse: an Overview
In the software you can choose from three Mouse Edit modes. Each of them provide different
mouse actions in the Event area.
The Edit Mode selector.
Working with Patterns
Editing Events
MASCHINE STUDIO - Manual - 284
